7.4

FITTING THE BOWL

1 - Using a straight edge mark the 2 sleeves where

they join the bowl.

2 - Remove the sleeves from the bowl and insert

them into the frame. Using a straight edge mark

the 2 sleeves where they join the wall.

Use soapy water

to facilitate insertion of the sleeves.

3 - Measure the distance (L) between the two marks

for both sleeves.

4 - Note this distance (L), adding an extra 3mm for

the fra

me end for both sleev

es. E.g.: If L=50mm,

the sleeve should be shortened by 53mm.

5 - Cut the sleeves using a hacksaw.

6 - Use a file to smooth the section where the cut

was made.

7 - Measure the thickness of the bowl’s rear section (B).

8 - If necessary, cut the anchor rods again so that

the section protruding from the wall is equal to

(B)+20mm.

9 - Shorten the flexible tube so that the section

otruding

from the wall is equal to (B) - 15 mm.

10 - Insert the supply sleeve and the discharge

sleeve into the bowl.

Then place the bowl onto the two anchor rods.

Use soapy water to facilitate insertion of the

discharge sleeve into the bowl and the pipe.

11 -

Once the bowl is correctly positioned, fix it using

the parts provided, whilst ensuring that the

parts are fitted in the correct order:

= seating washer = nut

= metal washer = cover

iii

FITTING THE FLUSH PLATE

1 -

Fix the small backplate of the plate onto the

frame using 2 grey screws .

If the casing is not particularly thick, shorten the

screws by breaking them at the notch designed

for this purpose.

2 -

Screw in the two actuation screws (the 2

remaining grey screws ).

If the casing is not particularly thick, shorten the

screws by simply breaking them at the notch

designed for this purpose.

3 -

Adjust the actuation screws so that the distance

• enable drainage to occur.

• prevent a continual flow.

4 -

Hook the bottom of the flush plate onto the

spring, then gently push it back, snapping the

plate onto the clips.

7.6

I FITTING THE CASING

Various materials can be used to make the casing

(brick, plasterboard, waterproof wooden panels, etc.).

Use the cut-out template provided to cut the various

holes (flush plate, bowl discharge and supply pipes,

bowl anchor rods).

1 - Top panel dimensions

2 - Bottom panel dimensions

7.4.a

7.4.b

7.5

CASING

PREPARING THE CASING

1 -

Place the frame in position .

2 -

Fix the PSE template onto the access hatch

using the two grey screws from the flush plate box.

3 -

Insert the flange into the supply elbow and

the flange into the macerator, and insert the

flexible tube onto the bowl’s anchor rods .

The casing thickness must be between 16 and

100mm. The casing and frame must be

interdependent. The front must be in 2 parts so

that the lower section facing the removable

frame can be used as an access hatch.

WATER TEST

1 -

Insert the water supply sleeve and the discharge

sleeve into the bowl.

Use soapy water

to facilitate insertion of the sleeves.

2 -

Position the bowl on the frame.

3 -

Turn on the water using the stop tap and wait

until the cistern is full.

4 -

Check the macerator’s plumbing and electrical

connections.

5 -

Using the pull cords, start the mechanism

manually.

6 -

Check the watertightness of both the supply and

discharge pipes.

7 -

Turn off the stop tap and empty the cistern.

8 -

Remove the bowl.

7.3.b

CONNECTING TO THE FEED WATER

CONNECTION

1 -

Remove the frame of the plate by lifting up the

two bolts .

2 -

Feed the feed water pipe into the cistern.

3 -

Connect the hose to the stop tap using either

the turn flare provided or directly with the nut on

the feed water pipe (in this case, ensure

watertightness with a fibre washer).

4 -

Connect the stop tap onto the ballcock and

ensure watertightness with a fibre washer).

7.3

7.3.a
