11
MAINTAINING THE MECHANISM
(fig.11.b)
(cleaning or replacing the sealing joint)
Follow the same steps as for maintaining the tap until
step 6, then:
1 - Grip the mechanism by its base and remove it
from the cistern.
Replacement parts:
Sealing joint : Réf. 34 2332-07
Whole mechanism : Réf. 32 4544-07
2 - Once maintenance has been completed, carry out
the steps in reverse order.
In order to ensure that
the mechanism is correctly
r
epositioned, its base is fitted with a foolproofing
device.
MAINTAINING THE MACERATOR
L’appareil The unit requires no special maintenance. The
unit is equipped with an active carbon filter in the vent. It
is not required to be connected to an external vent. This
filter should be replaced every year.
CLEANING/DESCALING
Regularly use an appropriate descaling agent such as
SFA SANIBROYEUR to descale and clean the
macerator and the bowl. This product is specially
designed to remove scale whilst respecting the
internal workings of your unit.
• Disconnect the macerator power supply.
• Pour a measure of descaling agent into the bowl.
• Leave it to stand for a few hours.
• Reconnect the macerator power supply.
• Rinse by flushi
ng twice.
This should be carried out every three months on
average, but you may need to adjust this schedule
depending on the hardness of your water.
MAINTENANCE
Some basic maintenance may be necessary during
normal usage of your SANIWALL
®
Pro
.
MAINTAINING THE TAP
(fig. 11.a)
(cleaning the filter, changing the membrane)
1 - Remove the flush plate by gently lifting it up and
then tilting it forwards.
2 - Remove the plate’s actuation screw.
3 - Unscrew the screws on the small backplate and
remove this.
4 - Remove the frame as shown in
7.3.a
.
5 - Turn off the stop tap and separate it from the
ballcock .
6 - Rotate the spacer supporting the ballcock and re
move this.
7 - Once the maintenance is complete, carry out
the above steps in reverse order, remembering to
turn the stop tap .
Replacement parts:
Membrane : Réf. 34 9513-07
Whole tap : Réf. 30 9503-07
u
d
d
11.a
11.b
11.c
11.d
USAGE AND PRECAUTIONS
Toilets installed with a SANIWALL
®
Pro
are to be used
just like any traditional toilet and require no special
maintenance. The macerator is automatically activated
once water reaches a certain level in the unit.
The SANIWALL
®
Pro
macerator is designed to
discharge toilet, washbasin and shower waste.
IT IS NOT INTENDED FOR EITHER COMMERCIAL OR
INDUSTRIAL USE.
WARNING!!! If away for long periods (e.g. holidays),
we recommend that you turn off the water supply to
the unit.
WARNING!!! Should the unit be used to discharge
anything other than toilet paper, faecal matter or
waste water the guarantee will be invalidated. Any
damage to the unit caused by maceration of foreign
bodies such as cotton, tampons, sanitary towels,
wipes, food products, condoms, hair, metal wood or
plastic objects, or by pumping liquids, such as
solvents and oils, will not be covered by the
guarantee.
10
ACTIVATING THE UNIT
Once all electrical and plumbing installations are
complete, flush the unit once. The unit should start
automatically and run for between 5 and 10 seconds
depending on the height of the discharge pipe. If it runs
for more than 20 seconds, check that the discharge
hose is not kinked (causing a blockage) or that the vent
is not blocked.
Flush several times. All pipes must be watertight. At the
s
ame time, if necessary, check the watertightness of
connections to any other sanitary appliances (e.g.
washbasin).
WARNING!!! The flushing system (as well as any other
sanitary appliances connected to the macerator) must
be completely watertight. Even a small leak could
cause the macerator to be activated unnecessarily.
9
STANDARDS
This appliance complies with EN 12050-3 (Lifting plant for
waste water containing faecal matter for limited applications)
and the European directives and standards concerning
electrical safety and electromagnetic compatibility.
8
