Setting up the monitor | 11
Setting up the monitor
Connecting the stand
NOTE: The stand is detached when the monitor is shipped from the factory.
NOTE: The following steps are applicable for connecting the stand that shipped
with your monitor. For setting up any other stand, see the documentation that
shipped with it.
To attach the monitor stand:
1.
Place the monitor on a soft cloth or cushion.
2.
Insert the tabs on the upper part of the stand in to the grooves on the back of
the monitor.
3.
Press down the stand till it snaps into place.
