12 | Setting up the monitor
Connecting your monitor
WARNING: Before you perform any of the procedures in this section, follow
the Safety instructions.
NOTE: Do not connect all cables to the computer at the same time. It is
recommend to route the cables through the cable-management slot before you
connect them to the monitor.
To connect your monitor to the computer:
1.
Turn off your computer and disconnect the power cable.
2.
Connect the VGA/HDMI cable from your monitor to the computer.
Connecting the VGA cable
Connecting the HDMI cable (sold separately)
