12 About Your Monitor
11 GND
12 DDC data
13 H-sync
14 V-sync
15 DDC clock
Plug and Play Capability
You can install the monitor in any Plug and Play compatible system. The monitor
automatically provides the computer with its Extended Display Identification Data (EDID)
using Display Data Channel (DDC) protocols so that the system can configure itself and
optimize the monitor settings. Most monitor installations are automatic. You can select
different settings if required.
Flat-Panel Specifications
Model number E1916HV / E1916HL E2016HV
Screen type Active matrix - TFT LCD Active matrix - TFT LCD
Panel Type TN TN
Viewable image
Diagonal
470.1 mm
(18.51 inches)
494.1 ± 0.02 mm
(19.5 ± 0.05 inches)
Horizontal Active
Area
409.8 mm
(16.13 inches)
432.0 ± 1.92 mm
(17.0 ± 0.08 inches)
Vertical Active
Area
230.4 mm
(9.07 inches)
239.76 ± 3.42 mm
(9.44 ± 0.13 inches)
Area
94417.92 mm
2
(146.35 inches
2
)
102552.65 ± 1050 mm
2
(158.84± 1.56 inches
2
)
Pixel pitch 0.30 x 0.30 mm
0.2712 ± 0.0012 x 0.2626
± 0.0074 mm
Viewing angle:
Horizontal 90° typical 90° typical
Vertical 65° typical 50° to 65° typical
Luminance
output
200 cd/m² (typical) 200 cd/m² (typical)
Contrast ratio 600 to 1 (typical) 600 to 1 (typical)
