Intel Software Guard Extensions
Fastboot Enable to set the speed of the boot process.
Default: Thorough.
Extend BIOS POST Time Configure the additional pre-boot delay.
Full Screen logo Enable or disable the full screen logo.
Warnings and Errors Configures the boot process behavior when
warnings or errors are detected.
Table 9. System setup options—Manageability
MEBx Hotkey Enable or disable the MEBx Hotkey function when
the system boots.
Table 10. System setup options—Virtualization Support menu
Virtualization Support
Virtualization Specify whether a Virtual Machine Monitor (VMM)
can utilize the additional hardware capabilities
provided by Intel Virtualization Technology.
VT for Direct I/O Specify whether a Virtual Machine Monitor (VMM)
can utilize the additional hardware capabilities
provided by Intel Virtualization Technology for
Direct I/O.
Table 11. System setup options—Wireless menu
Wireless
Wireless Switch Determine which wireless devices can be controlled
by the Wireless Switch.
Wireless Device Enable Enable or disable internal wireless devices.
Table 12. System setup options—Maintenance menu
Maintenance
Service Tag Display the system’s Service Tag.
Asset Tag Create a system Asset Tag.
102
