Removing the battery (half-
length)
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Prerequisites
Remove the base cover.
Procedure
1 Remove the four screws (M2x4) that secure the battery to the palm-rest
assembly.
2 Disconnect the battery cable from the system board.
19
