Replacing the power-adapter

port

WARNING: Before working inside your computer, read the safety

information that shipped with your computer and follow the steps in Before

working inside your computer. After working inside your computer, follow

the instructions in After working inside your computer. For more safety best

practices, see the Regulatory Compliance home page at

www.dell.com/

regulatory_compliance.

Procedure

1 Place the power-adapter port into the slot on the palm-rest assembly.

2 Route the power-adapter port cable through its routing guides on the palm-rest

assembly.

3 Replace the screw (M2x3) that secures the power-adapter port to the palm-

rest assembly.

4 Connect the power-adapter port cable to the system board.

Post-requisites

1 Replace the display assembly.

2 Replace the battery (half-length) or the battery (full-length).

3 Replace the base cover.
