Indesit ISL 60 V [7/68] Start and programmes
![Indesit ISL 60 V [7/68] Start and programmes](/views2/1026503/page7/bg7.png)
7
GB
High Heat
When available this button selects high heat. Press this
button and a high heat setting is selected and the light
above the button comes on. Timed programmes
have a default of low heat, if the light alongside the
button is on then pressing the button selects a low
heat setting and the light goes out.
Alarm
Available on all programmes and allows the buzzer
to give a signal at the end of the drying cycle, to
remind you that the clothes are ready to be removed.
Press the button and the light will show that the
option is selected.
Post Creasecare
The clothes are occasionally tumbled after the end of
the drying and cool tumble cycles, to help prevent
creases developing should you not be available to
remove the load immediately the programme is
complete.
●
Door Opening
Opening the door during a programme will stop the
dryer and have the following effects:
●
All 3 progress lights come on and the 3hr delay
light come on.
●
During a delay phase the delay will continue to
count down. The start button must be pressed to
resume the delay programme.
One of the delay lights will flash to show the
current delay setting.
●
The start button must be pressed to resume the
programme. The progress lights will change to
show the current status.
●
During the cool tumble or post creasecare phase
of a drying programme and anytime during an
Airing or Cool Tumble programme, the programme
will finish. Pressing the start button will re-start a
new programme at the beginning.
●
Changing the programmes knob will select a
new programme, after you press the start button.
You can use this to select the Cool Tumble
programme to cool the clothes, if you find them
dry enough.
●
Note
If you have a power cut, switch off the power or
remove the plug, press the START button and the
programme will resume.
●
PROGRAMMES knob
! Warning, if after pressing the start button, the
programmes knob position is changed, the new
position will NOT change the programme selected.
! Position 0, turning the knob to position 0 resets
and cancels a programme.
●
OPTION buttons / lights
These buttons are used to customise the selected
programme to your requirements. A programme must
have been selected on the programme knob before
an option can be selected. Not all options are available
for all programmes (see Start and Programmes). If an
option is not available and you press the button, the
buzzer will beep four times. If the option is available
there will be one beep and the option light above the
button lights to confirm the selection.
After the start button has been pressed only the
Alarm option can be changed.
Progress ( , , ) /
Delay (3hr 6hr 9hr 12hr) Lights
When the light above the delay button is on, these lights
flash to indicate the delay time is selected. During other
programmes they indicate the progress of the dryer,
each one comes on as the corresponding phase starts.
Time Delay
The start of some programmes (see Start and
Programmes) can be delayed for up to 12 hours in
3hr steps.
When a delayed start is in progress the light above the
delay button will be on and the selected delay period
light will flash (after the start button has been pressed).
To set a delayed start, press the Time Delay button,
and the light above the button will come on together
with the 3hr delay light. Pressing the button again will
advance the delay setting to 6hr, the 3hr light goes
out and the 6hr light is on. Each time you press the
button the delay setting advances 3 hours, as indicated
by the corresponding light. If the 12hr light is on,
pressing the button again will cancel the delay.
You can also cancel the delay by turning the
programmes knob to 0, wait for the buzzer to beep
and then turn back to your selected programme.
Pre Creasecare
When a delayed start has been selected, the clothes
are tumbled occasionally during the delayed period
to help prevent creases developing.
The Controls
Start and Programmes
