20
Part 2 - Appendix
System Log Types
Boot Up Panic On
System Shutdown Panic O
Restart Clear All Data
Upgrade Success Clear Disk
Upgrade Error Format Disk
Power Failure Disk Full
Time Changed Auto Deletion
Time Zone Change Search Begin
Time Sync. Search End
Time Sync. Failed Clip-Copy Begin
Disk Bad Clip-Copy End
Login Clip-Copy Cancel
Logout Clip-Copy Failure
Setup Begin Clip Copy User
Setup End Clip-Copy Begin
Remote Setup Change Clip-Copy Finished
Remote Setup Failure Clip Copy Duration of Video
Setup Import Clip Copy Camera
Setup Import Failure Callback Failed
Setup Export Factory Reset
Setup Export Failure Camera Upgrade Begin
Setup Export Canceled Camera Upgrade End
SNS Failure Camera Upgrade Failure
Schedule On Camera Upgrade User
Schedule O Camera Upgrade Camera
