IDIS DR-3108P [9/28] Accessories
![IDIS DR-3108P [9/28] Accessories](/views2/1265222/page9/bg9.png)
Part 1 – Introduction
9
Accessories
Upon unpackaging the product, check the contents inside to ensure that all the following accessories are included.
Network Video Recorder Power Cable Quick Guide
Manual and IDIS Center Program CD Optical USB Mouse IR Remote Control
Assembly Screws for Adding Hard
Disk Drives
SATA2 cables
