- 2 -
Contents
For the user
Safety information 3
Description of the appliance 4-5
Using your appliance 6
– Before you use the dryer for the first time
– Capacity
– Examples of laundry item weights
Program chart 7
– Consumption
Maintenance 8-9
– The filters
– The condenser
– Emptying the water tank
General information 10
If the machine is not working 11
Service 12
– Service and spare parts
For the installer
Technical data 12
Installation 13-14
– Positioning
– Electrical supply
– Wall mounting
Rukowodstwo po \kspluatacii 15
Damages
If the dryer has been damaged during transport, you
should immediately notify the company responsible for
delivering it.
Check that the dryer is undamaged. If you discover any
damage, faults or that anything is missing, you should
notify the dealer immediately.
Never leave packaging material in a place
where children may play with it.
Accessories supplied with the dryer
Console for wall mounting
Optional extra accessories
Mounting kit for installation on top of a washing machine
150 62 99-00
Drain hose 5647 12 28-10
You can ordered the extra accessories from the same
place where you bought the dryer or direct from the
supplier. (Please specify the relevant part number as
shown here).
Identification of materials
All materials used in packaging the dryer are
environmentally-friendly. The various plastics
used are identified and can be recycled:
• PE stands for polyethylene, which is used for the
bag around the dryer and the bag in which these
instructions were supplied.
• PS stands for (moulded) polystyrene, which is used
for the sections of packaging needed to cushion the
dryer.
The cardboard components of the packaging are made
from recyclable paper and should be taken to a collection
point for recycling.
Unpacking the machine
