Pioneer DEH-2320UB [6/84] Operating this unit

The cut-off frequency and output level can be ad-

justed when the subwoofer output is on.

Only frequencies lower than those in the selected

range are outputted from the subwoofer.

1 Press M.C. to display the setting mode.

2 Press M.C. to cycle between the cut-off frequency

and output level of the subwoofer.

Cut-off frequency (Cut-off frequency display

flashes.)—Output level (Output level display

flashes.)

3 Turn M.C. to select the desired setting.

Cut-off frequency: 50HZ —63HZ—80HZ—100HZ

—125HZ

Output level: -24 to +6

SLA (source level adjustment)

SLA (Source Level Adjustment) lets you adjust the vo-

lume level of each source to prevent radic al changes

in volume when switching between sources.

! Settings are based on the FM volume level, which

remains unchanged.

! The MW/LW volume level can also be adjusted

with this function.

! When selecting FM as the source, you cannot

switch to SLA.

1 Press M.C. to display the setting mode.

2 Turn M.C. to adjust the source volume.

Adjustment range: +4 to –4

3 Press M.C. to confirm the selection.

Initial Settings

Important

PW SAVE (power saving) is cancelled if the vehi-

cle battery is disconnected and will need to be

turned back on once the battery is reconnected.

When PW SAVE (power saving) is off, depending

on connection methods, the unit may continue to

draw power from the batter y if your vehicle's igni-

tion switch doesn't have an ACC (accessory posi-

tion).

1 Press and hold S (SRC/OFF) until the

unit turns off.

2 Display the function name.

# (DEH-2300UB, DEH-2300UBB and DEH-

2320UB)

Press S (SRC/OFF) and hold until function

name appears in the display.

# (DEH-2310UB)

Press M.C. and hold until function name ap-

pears in the display.

3 Turn M.C. to select the initial setting.

After selecting, perform the following proce-

dures to set the initial setting.

CLOCK SET (setting the clock)

Only for DEH-2310UB.

1 Press M.C. to display the setting mode.

2 Press M.C. to select the segment of the clock dis-

play you wish to set.

Hour—Minute

3 Turn M.C. to adjust the clock.

CLOCK (clock display)

Only for DEH-2310UB.

You can turn the clock display on or off.

The clock display disappears temporarily when you

per form other operations, but the clock display ap-

pears again after 25 seconds.

1 Press M.C. to turn the clock display on or off.

FM STEP (FM tuning step)

Normally, the FM tuning step employed by seek tun-

ing is 50 kHz. When AF or TA is on, the tuning step

automatically changes to 100 kHz. It may be prefer-

able to set the tuning step to 50 kHz when AF is on.

! The tuning step remains at 50 kHz during manual

tuning.

1 Press M.C. to display the setting mode.

2 Turn M.C. to select the FM tuning step.

50 KHZ (50 kHz)—100 KHZ (100 kHz)

3 Press M.C. to confirm the selection.

AUTO-PI (auto PI seek)

The unit can automatically search for a different sta-

tion with the same programming, even during preset

recall.

1 Press M.C. to turn Auto PI seek on or off.

AUX (auxiliary input)

Activate this setting when using an auxiliary device

connected to this unit.

1 Press M.C. to turn AUX on or off.

USB (plug and play)

Section

Operating this unit

This setting allows you to switch your source to USB

automatically.

1 Press M.C. to turn the plug and play function on

or off.

ON – When USB storage device is connected, de-

pending on the type of device, the source is auto -

matically switched to USB when you turn on the

engine. If you disconnect your USB storage de-

vice, this unit’s source is turned off.

OFF – When USB storage device is connected,

the source is not switched to USB automatically.

Please change the source to USB manually.

ILLUMI (illumination color select)

Only for DEH-2310UB.

1 Press M.C. to display the setting mode.

2 Turn M.C. to select the desired setting.

RED (red)—GREEN (green)

3 Press M.C. to confirm the selection.

SW CONTROL (rear output and subwoofer setting)

The rear speaker leads output and RCA output can be

used for full- range speaker or subwoofer connection.

If you switch to REAR-SP :SW, you can connect a rear

speaker lead directly to a subwoofer without using an

auxiliary amp.

Initially, REAR-SP is set for rear full-range speaker

connection (FUL).

1 Press M.C. to display the setting mode.

2 Turn M.C. to change the output and press to se-

lect.

REAR-SP—PREOUT

3 Turn M.C. to change the setting.

REAR-SP: FUL—SW

PREOUT: SW—REA

! Even if you change this setting, there is no

output unless you turn the subwoofer output

on (refer to SUBWOOFER1 (subwoofer on/off

setting) on page 9).

! If you change this setting, subwoofer output

in the audio menu will return to the factory

settings.

DEMO (demo display setting)

1 Press M.C. to turn the demo display on or off.

SCROLL (scroll mode setting)

When ever scroll is set to ON, recorded text informa-

tion scrolls continuously in the display. Set to OFF if

you prefer the information to scroll just once.

1 Press M.C. to turn the ever scroll on or off.

TITLE (multi-language)

This unit can display the text information of a com-

pressed audio file even if they are embedded in a

Western European or Russian language.

! If the embedded language and the selected lan-

guage setting are not the same, text information

may not be displayed properly.

! Some characters may not be displayed properly.

1 Press M.C. to display the setting mode.

2 Turn M.C. to select the desired setting.

EUROPEAN (European)—RUSSIAN (Russian)

3 Press M.C. to confirm the selection.

PW SAVE (power saving)

Only for DEH-2300UB, DEH-2300UBB and DEH-

2320UB.

Switching this function on enables you to reduce the

consumption of battery power.

! Turning on the source is the only operation al-

lowed when this function is on.

1 Press M.C. to turn the power save on or off.

Using an AUX source

1 Insert the stereo mini plug into the

AUX input jack.

2 Press S (SRC/OFF) to select AUX as the

source.

Note

AUX cannot be selected unless the auxiliary set-

ting is turned on. For more details, refer to AUX

(auxiliary input) on the previous page.

Sound muting

Only for DEH-2300UB, DEH-2300UBB and

DEH-2320UB.

Sound is muted automatically when:

! A call is made or received using a cell

phone connected to this unit.

! Voice guidance is output from a connected

Pioneer navigation unit.

The sound is turned off, MUTE is displayed

and no audio adjustments, except volume con-

trol, are possible. Operation returns to normal

when the phone connection or the voice gui-

dance is ended.

English

Section

Operating this unit

<CRD4528-A/N>6
