Sony SLV-EZ727AZ [66/68] Troubleshooting continued

Additional Information

Symptoms caused by contaminated video heads

• Normal picture • Rough picture • Unclear picture • No picture (or

black & white

screen appears)

initial

contamination

terminal

Troubleshooting (continued)
