Hamax 2017 Zenith Relax W Carrier Adapter серо-черный — как отделить сиденье от адаптера багажника: пошаговая инструкция [68/76]

Содержание

• Hx_zenith_relax_carrier_adapter_um_cover_single_paged_2014 11 25_print p.1
• User manual p.3
• Ø 10 20 mm p.3
• Important p.3
• 180 mm p.3
• Zenith relax w carrier adapter p.5
• Zenith relax w carrier adapter p.6
• Hx_zenith_relax_carrier_adapter_um_spreads_2014 11 25_print p.9
• Manuel de l utilisateur fr p.10
• Gebrauchsanleitung de p.11
• Monterings og bruksanvisning no p.12
• Návod k použití cz p.13
• Monterings og bruksanvisning p.13
• Brugervejledning dk p.15
• Manual del usuario es p.16
• Käyttöohjeet fi p.17
• Manual del usuario p.17
• Korisnički priručnik hr p.18
• Korisnički priručnik p.19
• Felhasználói útmutató hu p.19
• Manuale d uso it p.20
• Manuale d uso p.21
• 설치 p.22
• 사용자 설명서 kr p.22
• 사용 p.22
• 경고 p.22
• 유지 보수 p.23
• 사용자 설명서 p.23
• Gebruikershandleiding nl p.23
• Instrukcja montażu i użytkowania pl p.24
• Instruções de utilização pt p.25
• Instrukcja montażu i użytkowania p.25
• Manualul utilizatorului ro p.27
• Руководство пользователя ru p.28
• Руководство пользователя p.29
• Bruksanvisning se p.29
• Uzivatelska prirucka si p.30
• Sk návod na použitie p.31
• Ръководство за потребителя bg p.33
• Kullanım kılavuzu tr p.34
• Посібник користувача ua p.35
• Zenith relax w carrier adapter p.38
• Unscrew the carrier adapter p.38
• Screw the claws outward by turning the knob 5a counterclockwise untill the claws fit around the luggage carrier the knob needs to be pushed in while turning p.38
• Zenith relax w carrier adapter p.40
• Position the seat 1 as much towards the front as possible while still leaving room for reclining the seat make sure the centre of gravity mark 8 is less than 10 cm behind the rear hub p.40
• Place the seat on the luggage carrier p.40
• Fasten the seat on the luggage carrier p.42
• Zenith relax w carrier adapter p.42
• Fix the seat to the luggage carrier by pushing in and turning the knob 5a clockwise until the claws grasp the side tubes of the luggage carrier tighten hard enough to fix the seat securely and prevent it from sliding make it a rule to check this before starting a trip with the bike p.42
• Zenith relax w carrier adapter p.44
• The additional security strap needs to be secured to the frame or seat post lead the security strap 5c through the holes as shown in pic 1 2 then pull at the end to tighten it if needed the length of the strap can be adjusted p.44
• Fasten the additional security strap p.44
• Zenith relax w carrier adapter p.46
• How to release the foot rest 4 release the footrest handle on the back by flipping it upwards move the foot rest 4 to the preferred height and fasten the foot rest by pressing the foot rest handle down p.46
• Foot rest adjustment p.46
• Zenith relax w carrier adapter p.48
• How to fasten release the foot strap a to fasten the foot strap put the strap into the track and pull down to preferred length the strap will automatically lock it s only possible to tighten the strap when it is in the track to loosen the foot strap just pull it out of the track p.48
• Foot strap adjustment p.48
• Zenith relax w carrier adapter p.50
• To mount the extra footguard 7 press the footguard into the fitting grooves until it clicks p.50
• Extra footguard p.50
• Opposite view p.51
• Restraint system p.52
• Zenith relax w carrier adapter p.52
• The restraint system 2 can be attached and detached by pressing in or out the buckle 3 shown in pic 1 it is important to press at the middle of the buckle button pic 2 3 when detaching the restraint system the buckle button needs an adult force to open this is for the safety of the child so they cannot open it p.52
• Where to push p.53
• Pic 2 pic 3 p.53
• Ok not ok p.53
• Zenith relax w carrier adapter p.54
• The restraint system length can be adjusted by adjusting buckle a and b to adjust buckles a b hold the buckle as shown in pic 1 by pressing the red button the belt loosens by pulling the buckle upwards to tighten the restraint system just pull end of the belt straps pic 2 move the buckle c up to secure the belt so it cannot fall down from the child s shoulders pic 3 p.54
• Chest buckle adjustment p.54
• Zenith relax w carrier adapter p.57
• To recline the seat press the reclining knob 6 down and at the same time twist to the required position p.57
• Reclinable function p.57
• Zenith relax w carrier adapter p.58
• Nb never leave your child alone in the bicycle child seat please note that the kick stand is not a suitable support to hold the bicycle with a child in the seat p.58
• Before embarking on a bicycle trip p.58
• Adjust the restraint system 2 adjust the foot rests 4 and fasten foot straps check if the carrier adapter 5 still is secured well and does not slide always wear helmets both child and adult p.58
• How to remove the carrier adapter p.62
• Zenith relax w carrier adapter p.62
• The carrier adapter for luggage carrier mounting can be taken off the zenith seat and can be replaced by a carrier bow to do this you need to take the seat off the carrier adapter unscrew the knob 5a by pushing it in and turning counterclockwise until the seat is loose enough to take off p.62
• Zenith relax w carrier adapter p.66
• Turn the seat 1 upside down twist the locking pin 5b to the unlocked position pic 1 then push it through from the opposite side of the seat while pulling it out pic 2 3 p.66
• How to remove the carrier adapter p.66
• Zenith relax w carrier adapter p.68
• You can now separate the seat 1 and carrier adapter 5 by lifting off the carrier adapter p.68
• How to remove the carrier adapter p.68
• Zenith relax w carrier adapter p.70
• Mount the carrier bar to the seat insert the carrier bow through the holes lengthwise under the seat base insert a carrier bow locking pin note that this is a different part than the carrier adapter locking pin through the holes under the seat base keeping it in unlocked position to allow final adjustment insert the carrier bow into the fastening bracket on the bicycle and adjust the correct lengthwise position max 10 cm between the centre mark on the seat and the rear hub after adjustment lock the seat by turning the locking pin locking pin to locked position p.70
• For detailed instructions and illustrations to each step please see our website www hamax com p.70
• Changing to a carrier bow p.70
