14
Image fuzzy or cropped
Change the computer's "Resolution" setting to match
the projector's resolution. Varies per operating system.
Image clear and not cropped
Image not centered on screen
Move projector, adjust height
Correct image
Problem Solution Result
A
A
A
Adjust horizontal or
vertical position in
Advanced Menu >
Image > PC... menu
