15
Image not square Adjust Keystone on keypad
Square image
Image not sharp
Adjust Sharpness in the Basic Menu
Correct image
Image does not fit 4:3 or 16:9 screen
Change aspect ratio to 4:3 or 16:9 in Basic Menu >
Aspect Ratio menu
Correct image
Problem Solution Result
