СТИРАЛЬНАЯ МАШИНА АВТОМАТ
AUTOMATIC WASHING MACHINE
СТИРАЛЬНАЯ МАШИНА АВТОМАТ
AUTOMATIC WASHING MACHINE
ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ • USEr GUIdE ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ • USEr GUIdE
ТЕХНИЧЕСКИЕ ХАРАКТЕРИСТИКИ и КОМПЛЕКТАЦИЯ
Модель
KF-ASL50801MWB
KF-ASL50101MWB
KF-ASL60803MWB
KF-ASL60101MWB
KF-ASL70102MWB
Цвет Белый
Напряжение питания/частота тока, В/Гц 220-240/50
Максимальная загрузка сухого белья, кг 5 5 6 6 7
Номинальная потребляемая мощность, Вт 1950 1950 1950 1950 1950
Максимальное число оборотов при отжиме, об/мин 800 1000 800 1000 1000
Индикация LED
Цвет индикации Красный
Длина шнура электропитания, м 1,5 1,5 1,5 1,5 1,5
Длина шланга для залива воды, м 1 1 1 1 1
Длина шланга для слива воды, м 1,6 1,6 1,6 1,6 1,6
Класс энергоэффективности A+ A+ А+ А++ А++
Класс стирки A A A A A
Класс отжима D C D C C
Остаточная влажность белья, % 70 61 70 61 61
Годовое энергопотребление, кВт*ч/год 169 169 169 173 173
Годовой расход воды, л/год 8250 8250 8250 9240 9240
Максимальный расход воды за цикл стирки, л/цикл 46 46 46 48 48
Уровень шума при стирке/отжиме, дБ 59/74 59/74 59/74 59/74 59/74
Объем барабана, не менее, л 38 38 38 38 38
Диаметр загрузочного отверстия, мм 300 300 300 300 300
Внешний диаметр люка, мм 420 420 420 420 420
Габариты (ШхГхВ), мм 595х450х850
Габариты в упаковке (ШхГхВ), мм 650х555х885
Вес нетто/брутто, кг 52/55 54/57 52/55 54/57 54/57
Основные программы стирки
Число программ 23
Хлопок ECO 40°С да
Хлопок ECO 60°С да
Хлопок
да
Хлопок 20°С да
Хлопок 30°С да
Хлопок 40°С да
Хлопок 60°С да
Модель
KF-ASL50801MWB
KF-ASL50101MWB
KF-ASL60803MWB
KF-ASL60101MWB
KF-ASL70102MWB
Хлопок 90°С да
Синтетика
да
Синтетика 40°С да
Синтетика 60°С да
Ежедневная стирка 15' да
Ежедневная стирка 30' да
Ежедневная стирка 45' да
Окончание через 3 ч да
Окончание через 6 ч да
Окончание через 9 ч
да
Шерсть
да
Деликатная 30°С да
Полоскание+Отжим да
Слив да
Отжим да
Автоочистка да
Опции
Дополнительное полоскание да
Предварительная стирка да
Без отжима да
Пауза в работе да
Особенности
Возможность отключения звукового сигнала да
Защита от детей да
Автобаланс да
Антипена да
Контроль перегрева да
Контроль перелива да
Комплектация
Стиральная машина 1 шт.
Шланг заливной 1 шт.
Заглушки 1 комплект
Кронштейн (опция) 1 шт.
Инструкция по эксплуатации с гарантийным талоном 1 шт.
Упаковка 1 шт.
