Dear Buyer!
We congratulate you on having bought the device under trade name
ТМ
KRAFT.
We are sure that our devices will become faithful and reliable assistance in your
housekeeping.
Avoid extreme temperature changes. Rapid temperature
change (e.g. when the unit is moved from freezing temperature to a warm
room) may cause condensation inside the unit and a malfunction when it is
switched on. In this case leave the unit at room temperature for at least 8 hours
before switching it on.
Contents
SAFETY PRECAUTIONS ......................................................................................... 28
OVERVIEW OF WASHING MACHINE ..................................................................... 30
INSTALL WASHING MACHINE ................................................................................ 31
OPERATE WASHING MACHINE .............................................................................. 34
VIEW OF CONTROL PANEL ................................................................................... 38
MAINTENANCE ........................................................................................................ 43
TROUBLESHOOTING.............................................................................................. 46
REMOVE THE PROBLEMS ..................................................................................... 47
PRODUCT SPECIFICATIONS .................................................................................. 48
APPENDIX ................................................................................................................ 50
