20 21
СТИРАЛЬНАЯ МАШИНА АВТОМАТ
AUTOMATIC WASHING MACHINE
СТИРАЛЬНАЯ МАШИНА АВТОМАТ
AUTOMATIC WASHING MACHINE
ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ • USEr GUIdE ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ • USEr GUIdE
ЭКО
Для более эффективной стирки используется более продолжительное время
стирки. Для установки режима ЭКО необходимо выбрать программу «Хлопок».
Затем одновременно нажмить и удерживать в течении 3 сек кнопки «Температура»
и «Отжим», на дисплее загорится значок
. Данную программу можно установить
только для стирки хлопка при температуре 60 – 40°С.
ОТКЛЮЧЕНИЕ ЗВУКОВОГО СИГНАЛА
После запуска машины, нажмите и удерживайте в течение 3 секунд кнопку «Тем-
пература» до появления звукового сигнала. Для восстановления функции повто-
рите действие.
Внимание:
После отключения звуковой сигнал не будет активирован до отмены функции
отключения.
ТАБЛИЦА ПРОГРАММ СТИРКИ Модель KF-SТ60102MWL / KF-ST60103MWLS
ПРОГРАММА
Макс.
Загруз-
ка (кг)
Отсеки для детергентов
Темпе-
ратура
(°С)
Время
(мин)
Макс.
скорость
отжима
(об/мин)
Предвари-
тельная
стирка
Основ-
ная
стирка
Опола-
скива-
тель
Интенсивная
стирка
6.0 Х
40 120 1000
Хлопок 60 °С 6.0 Х
60 90 1000
Хлопок 40 °С 6.0 Х
40 89 1000
Хлопок 20 °С 6.0 Х
20 82 1000
Экспресс-стирка 2.0 Х
Холод-
ная
вода
15 800
Ежедневная
стирка
6.0 Х
40 104 800
Полоскание и от-
жим
6.0 Х Х
- 35 1000
Детские вещи 6.0 Х
60 110 1000
Спортивная одежда 3.0 Х
40 87 800
Синтетика 3.0 Х
40 77 800
Смешанное бельё 6.0 Х
40 79 1000
Деликатная стирка 2.5 Х
30 70 600
Шерсть 2.0 Х
40 64 400
Слив - Х Х Х - 1 0
Отжим 6.0 Х Х Х - 13 1000
Обязательно использовать детергент, без которого стирка будет неэффективной.
Использовать стиральный порошок или ополаскиватель, если это необходимо.
Х Нет необходимости использовать детергент или ополаскиватель.
Решение проблем, возникших в ходе эксплуатации
стиральной машины
Проблема
Предполагаемая причина/Способ устранения
Стиральная машина не работает
- Открыть кран до упора
- Прочистить ситечко на шланге подвода воды
- Закрыть дверцу стиральной машины
- Нажать на кнопку «Старт/Пауза»
Вода под стиральной машиной
- Правильно подсоединить наливной шланг под-
вода воды
Стиральная машина не отжимает
- Вынуть и еще раз загрузить вещи в барабан,
очистить фильтр насоса
Неприятный запах в барабане
стиральной машины
- Включить цикл автоочистки с пустым бараба-
ном (см. таблицу программ)
В барабане нет воды
- На дисплее высвечивается код ошибки Е10.
Открыть водопроводный кран
В отсеке для ополаскивателя
остается вода
- Нажать на „грибок», который находится в цен-
тральной камере отсека
Плохой отжим
- Необходимо правильно дозировать моющее
средство в зависимости от степени загрязнения
вещей и жесткости воды (см. рекомендации на
упаковке моющего средства)
- Прочистить фильтр насоса
Стиральная машина не набирает
воду
- Открыть водопроводный кран
- Проверить параметры программы
- Проверить напор воды
- Еще раз подсоединить шланг подвода воды
- Закрыть дверцу стиральной машины
- Проверить и убедиться, что шланг не перекру-
чен и не пережат
Стиральная машина набирает и
сливает воду одновременно
- Проверить и убедиться, что конец сливного
шланга располагается выше уровня воды в сти-
ральной машине (шланг должен располагаться
на высоте 0,6-1 м от пола)
Неправильный слив воды
- Проверить состояние фильтра насоса
- Проверить состояние сливного шланга
- Проверить расположение сливного шланга, ко-
торый должен располагаться на высоте 0,6-1 м от
пола
Стиральная машина вибрирует
- Проверить и убедиться, что сняты все транс-
портные блокировки
- Отрегулировать положение стиральной маши-
ны по уровню в разных плоскостях
- Зафиксировать ножки (затянуть контргайки)
Появляется большое количество
пены через отсеки для стираль-
ного порошка
- Уменьшить дозу моющего средства
- Проверить жесткость воды, а также количество
и тип применяемого детергента
