2 3
СТИРАЛЬНАЯ МАШИНА АВТОМАТ
AUTOMATIC WASHING MACHINE
СТИРАЛЬНАЯ МАШИНА АВТОМАТ
AUTOMATIC WASHING MACHINE
ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ • USEr GUIdE ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ • USEr GUIdE
УВАЖАЕМЫЙ ПОКУПАТЕЛЬ!
Поздравляем Вас с приобретением изделия торговой марки
TM
KRAFT.
Уверены, что наши изделия будут верными и надежными помощниками в Вашем
домашнем хозяйстве.
Не подвергайте устройство резким перепадам температур. Резкая смена
температуры (например, внесение устройства с мороза в теплое помещение)
может вызвать конденсацию влаги внутри устройства и нарушить его
работоспособность при включении. Устройство должно отстояться в теплом
помещении не менее 8 часов.
Прежде чем включить стиральную машину, внимательно ознакомьтесь
с настоящей инструкцией по ее эксплуатации!
Содержание
ОБЩАЯ ИНФОРМАЦИЯ ..............................................................................................4
УКАЗАНИЯ ПО БЕЗОПАСНОСТИ И УТИЛИЗАЦИЯ ................................................ 5
УСТАНОВКА СТИРАЛЬНОЙ МАШИНЫ .................................................................... 6
ОПИСАНИЕ СТИРАЛЬНОЙ МАШИНЫ ...................................................................... 9
УКАЗАНИЯ ПО ОБСЛУЖИВАНИЮ ......................................................................... 13
ОПИСАНИЕ ПРОГРАММ СТИРКИ ..........................................................................15
РЕШЕНИЕ ПРОБЛЕМ, ВОЗНИКШИХ В ХОДЕ ЭКСПЛУАТАЦИИ
СТИРАЛЬНОЙ МАШИНЫ. .........................................................................................21
ОЧИСТКА ................................................................................................................... 22
ТЕХНИЧЕСКИЕ ХАРАКТЕРИСТИКИ ........................................................................ 24
ГАРАНТИЯ И СЕРВИСНОЕ ОБСЛУЖИВАНИЕ ....................................................... 26
