6
ENGLISH (Original instructions)
Explanation of general view
SPECIFICATIONS
• Due to our continuing program of research and development, the specifications herein are subject to change without
notice.
• Specifications and battery cartridge may differ from country to country.
• Weight, with battery cartridge, according to EPTA-Procedure 01/2003
Intended use
ENE019-1
The tool is intended for the sawing of wood, plastic and
metal materials. As a result of the extensive accessory
and saw blade program, the tool can be used for many
purposes and is very well suited for curved or circular
cuts.
General Power Tool Safety
Warnings GEA010-1
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and
instructions for future reference.
CORDLESS JIG SAW SAFETY
WARNINGS
GEB045-2
1. Hold power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring. Cutting
accessory contacting a “live” wire may make exposed
metal parts of the power tool “live” and could give the
operator an electric shock.
2. Use clamps or another practical way to secure and
support the workpiece to a stable platform. Holding
the work by hand or against your body leaves it
unstable and may lead to loss of control.
3. Always use safety glasses or goggles. Ordinary
eye or sun glasses are NOT safety glasses.
4. Avoid cutting nails. Inspect workpiece for any
nails and remove them before operation.
5. Do not cut oversize workpiece.
6. Check for the proper clearance beyond the
workpiece before cutting so that the blade will not
strike the floor, workbench, etc.
7. Hold the tool firmly.
8. Make sure the blade is not contacting the
workpiece before the switch is turned on.
9. Keep hands away from moving parts.
10. Do not leave the tool running. Operate the tool
only when hand-held.
11. Always switch off and wait for the blade to come
to a complete stop before removing the blade from
the workpiece.
12. Do not touch the blade or the workpiece
immediately after operation; they may be
extremely hot and could burn your skin.
13. Do not operate the tool at no-load unnecessarily.
14. Some material contains chemicals which may be
toxic. Take caution to prevent dust inhalation and
skin contact. Follow material supplier safety data.
15. Always use the correct dust mask/respirator for
the material and application you are working with.
1. Red indicator
2. Button
3. Battery cartridge
4. Cutting action changing lever
5. Lock-off button
6. Switch trigger
7. Blade holder
8. Bolt
9. Hex wrench
10. Blade
11. Roller
12. Hook
13. Dust cover
14. Cutting line
15. Base
16. Edge
17. Graduation
18. Starting hole
19. Hose
20. Rip fence (Guide rule)
21. Fence guide
22. Rip fence
23. Threaded knob
24. Pin
25. Aluminum base
26. Anti-splintering device
27. Cover plate
Model JV143D JV183D
Length of stroke 18 mm 18 mm
Strokes per minute (min
-1
) 0 - 2,900 0 - 2,900
Blade type B type B type
Max. cutting capacities
Wood 65 mm 65 mm
Mild steel 6 mm 6 mm
Aluminum 10 mm 10 mm
Overall length 245 mm 248 mm
Net weight 1.9 kg 2.0 kg
Rated voltage D.C. 14.4 V D.C. 18 V
