Sony KV-29CL10K [11/52] Connecting optional equipment using optional equipment

Содержание

• Chassis 1
• Fdtrinitron 1
• Service manual fe 2 1
• Circuit adjustments 2
• Diagrams 2
• Disassembly 2
• Electrical parts list 2
• Explodedviews 2
• General 2
• Set up adjustments 2
• Table of contents 2
• Warning uk models only 3
• 14111z 113 i 4
• 9 0 0 p r r r 4
• Front connection panel 4
• Pin connector 4
• Rear connection panel 4
• Fe 2 self diagnostic software 5
• How to enter into table 2 5
• As in the manual 6
• General 6
• Instruction manual the page numbers of the operating instruction manual remain 6
• Section 1 6
• Switching on the tv and automatically tuning 6
• The operating instructions mentioned here are partial abstracts from the operating 6
• Introducing and using the menu system 7
• Menu guide 7
• Вввш b0bi 9
• Fastext 10
• Teletext 10
• Connected to this scart 11
• Connecting a vcr 11
• Connecting a vcr that supports smartlink 11
• Connecting optional equipment using optional equipment 11
• If you have connected a decoder to the scart or through a vcr 11
• Specifications 12
• Troubleshooting 12
• 1 rear cover removal 13
• 2 chassis removal and refitting 13
• Disassembly 13
• Section 2 13
• 3 a board removal step 1 2 4 a board removal step 2 14
• 5 service position 14
• 6 picture tube removal 15
• Before removing 15
• How to handle the anode cap 15
• Removal of the anode cap 15
• Removing procedures 15
• The anode cap 15
• Warning 15
• 1 removingthe plates 16
• 2 refittingthe plates 16
• Bottom plates 16
• For safety reasons on no account should the plates be re 16
• Moved and not refitted after servicing 16
• Removal and replacement ofthe main bracket 16
• 1 beam landing 17
• Caution 17
• Section 3 17
• Set up adjustments 17
• 2 convergence 18
• Horizontal and vertical static convergence 18
• Operation of the bmc hexapole magnet 18
• Preparation 18
• Geometry adjustment ych adjustment 19
• Htil adjustment 19
• Preparation 19
• Screen comer convergence 19
• Tlv adjustment 19
• 3 focus adjustment 20
• G2 adjustment 20
• Layout of each control 3 4 screen g2 white balance 20
• White balance adjustment for tv mode 20
• 1 electrical adjustments 21
• Circuit adjustments 21
• How to enter into the service mode 21
• Section 4 21
• Deflection system adjustment sub colour adjustment 22
• Sub brightness adjustment 22
• Sub contrast adjustment 22
• 2 test mode 1 23
• 3 test mode 2 23
• 2 circuit board location 26
• 3 schematic diagrams and 26
• And marked a are critical for safety replace only with the part numbers specified in the parts list 26
• Les composants identifiés par une trame et 26
• Par une marque a sont d une importance critique pour la sécurité ne les remplacer que par des pièces de numéro spécifié spedfied 26
• Printed wiring boards 26
• Reference information 26
• The components identified by shading 26
• A board differencetable 27
• A board ic voltagetable a board waveforms 27
• A board semiconductorvoltagetable 27
• Díaíaf a 28
• A board schamatlc diagram power supply page 1 4 29
• A board schematic diagram deflection page 2 4 30
• A board schematic diagram video page 3 4 31
• A board schematic diagram audio page 4 4 32
• A b c d e f g h i j k l m n 33
• C board schematic diagram r g b out 33
• C board semiconductor voltages c board ic voltages 33
• C board waveforms 33
• Ctci kaeo 33
• Rei no pin n 33
• Vo o h 33
• Voltiflo 33
• C printed wiring board conductor side 34
• Df printed wiring board conductor side 34
• Df board schamatlc diagram dynamic focus 35
• Rrri n 35
• Semiconductors 36
• 5 ic block diagrams 38
• 1 chassis 39
• And marked a are critical tor safety replace only with the part numbers specified in the parts list 39
• Exploded views 39
• Ikms with no pari number and no duscriplion arc not 39
• Ilie construction parts of an assembled part are indicated 39
• Items marked are not stocked 39
• Note les composants indentifies par une 39
• Note trie components identified by shading 39
• Section 6 39
• Since they are seldom required for routine service some delay should be anticipated when ordering these items 39
• Stocked because they are seldom required for routine service 39
• Trame et par une marque a sonte d une importance critique pour la sécurité ne les remplacer que par des pieces du numéro spécifié 39
• With a collation number in ilie remark column 39
• 2 picture tube 40
• A board common parts 41
• A board variant parts list 41
• C board complete parts list 42 41
• Electrical parts list 41
• Miscellaneous 41
• Parts listing table of contents 41
• Remote commander 41
• Section 7 41
• And marked a are critical for safety replace only with the part numbers specified in the parts list 42
• I a 1302 074 a c board complete i 42
• Note the components identified by shading 42
• A 1302 073 a a board complete kv 29cl1 oe 43
• A 1302 131 a a board complete kv 29cl1 ob 43
• A 1302 132 a a board complete kv 29cl1 ou 43
• A board common parts 43
• Kv 29cl10k 43
• And marked a are critical for safety replace only with the part numbers specified in the parts list 45
• Note the components identified by shading 45
• And marked a are critical for safety replace only with the part numbers specified in the parts list 46
• Note the components identified by shading 46
• And marked a are critical for safety replace only with the part numbers specified in the parts list 47
• Note the components identified by shading 47
• And marked a are critical for safety replace only with the part numbers specified in the parts list 50
• Note the components identified by shading 50
• A board variant parts kv 29cl10b miscellaneous 51
• A board variant parts kv 29cl10e kv 29cl10k 51
• A board variant parts kv 29cl10u 51
• Accessories and packaging materials 51
• And marked a are critical for safety replace only with the part numbers specified in the parts list 51
• Note the components identified by shading 51
• Remote commander 51
• 2003 3 52
• 927 439 01 52
• A new tv repair assistance tool that combines ease of use and powerful pc software tools to allow you to save valuable time during many tv repairs 52
• Cp7100 1 printed in u k 52
• English 52
• Partnumbers trace starter kit trace interface software 9 948 320 70 52
• Pc requirements ibm compatible pc with operating system windows95 windows98 or windowsnt 52
• Service promotions dept 52
• Sony corporation 52
• Sony uk 52
• Trace ir add on ir interface remote commander software 9 948 320 80 52
• Trace software for users of the l2c link interface 9 948 340 80 52

Похожие устройства

• Electrolux EFP/P-2520LS Инструкция по эксплуатации
• Electrolux EFP/W-1100ULS Инструкция по эксплуатации
• Electrolux EFP/P-3020LS Инструкция по эксплуатации
• Electrolux EFP/F-200RC Инструкция по эксплуатации
• Mystery MMK-702U Руководство пользователя
• Marvo KM-900W Инструкция по эксплуатации
• Marvo KM400 USB Инструкция по эксплуатации
• Maxi-Cosi Opal Concrete Grey Инструкция по эксплуатации
• Maxi-Cosi Milo Fix Sparkl Grey Инструкция по эксплуатации
• Maxi-Cosi Milo Fix River Blue Инструкция по эксплуатации
• Maxi-Cosi Milo Fix Origami Red Инструкция по эксплуатации
• Maxi-Cosi Milo Fix Digital Rain Инструкция по эксплуатации
• Maxi-Cosi Milo Fix Denim Heart Инструкция по эксплуатации
• Maxi-Cosi Milo Fix Concrete Grey Инструкция по эксплуатации
• Maxi-Cosi Milo Fix Black Raven Инструкция по эксплуатации
• Maxi-Cosi Milo Fix Black Crystal Инструкция по эксплуатации
• Maxi-Cosi Axiss Fix Triangle Flow Инструкция по эксплуатации
• Maxi-Cosi Axiss Fix Origami Red Инструкция по эксплуатации
• Maxi-Cosi Axiss Fix Mosaic Blue Инструкция по эксплуатации
• Maxi-Cosi Axiss Fix Digital Black Инструкция по эксплуатации

Connecting Optional Equipment Using Optional Equipment Ji Si Using the following instructions you can connect a wide range of optional equipment to your TV set Connecting cables are not supplied 1 Conned your equipment lo the designated IV socket as indicated in the previous page 2 Switch on Ihe connected equipment 3 To watch the picture of the connected equipment press the Q button repeatedly until the correct inpuL symbol appears on Ihe screen Symbol 1 Input Signals Audio video input signal through the Scart connector E e RGBinpuLsignal through Lhe Scarl connector 0 lhis symbol appears only if a RGB source has been connected 2 Audio video input signal through Lhe Scarl connector Q 2 S Video input signal through the Scart connector 0 3 Video input signal through the phono socket H nd Audio input signal through 0 P ess button on Lhe remote control lo reLurn lo Ihe normal TV picture Connecting a VCR To connect a VCR please refer to the section Connecting the aerial and VCR of this instruction manual Wc raommend you conn PC I your VCR using a scar I load If you do nol have a scar I load Lu no in Hi o VCR testsignal lo lhe TV programme number by using lhe Manual Programme P CSCL option for details of how lo manually programme these presets seo page 14 slop a Refer to your VCR instruction manual to find out how to find the output channel of your VCR Connecting a VCR that supports SmartLink KSI SmartLink is a direct link between the TV set and the VCR For more information on Smarll ink please refer LO the instruction manual of your VC R If you uso a VC R thal supports Smarll ink pleaso connect Ihe VC R by using a Scarl load to the Scart UL 2 O 0 If you have connected a decoder to the Scart or through a VCR connected to this Scart Select the Manual Programme Preset option in the SetUp menu and after entering in the IX coder option select On by using or Repeat this op Lion for oa ch scrambling signal This option is only available depending on the country you have selected in the I anguago Cx untry menu con Li nued For Mono Equipment Connect Ihe phono plug lo Ihe I G S l socket on Lhe front of Ihe TV and select 03 inpuL signal using the instructions above Finally refer to the Sound Adjustment section of this manual and select Dual Sound A on lho sound menu screen seepage ID
