Specifications Troubleshooting St Here are some simple solutions to the problems which may affect the picture and sound TV system Sound Output Depending on you г cou n Lrv selection B G ILD K 2x10 W music power 2x5W RMS Colour system Power Consumption PAL SLCAM NTSC 3 58 4 43 only Video In 94 W Channel Coverage 0 5 W VI1Г L2 L12 UHF R2I R69 CATV S1 S2Ü HYPFR S2I S4I D К R1 R12 R21 R69 N Solution No pic Lum screen is dark and no sound Check the aerial connection Plug the TV in and press the Q button on the front of Lhe TV If lhe standby indicator is on press I O button on the remote control Poor or no picture screen is dark buL good sound Using the menu system select the Picture Adjuslmenr menu and select Reser Lo return lo lhe factory saltings sae paga 10 No picture or no menu information from equipment connected to the Scar l conn ec Lor Check that the optional equipment is on and press the Q button repeatedly on the remote control until the correct in pul symbol is displayed on lhe screen see page 19 Good picture no sound Press the button on the remote control Check that TV Speakers is On on the Sound Adjuslmenr menu sac page 11 Check that headphones are not connected No colour on colour programmes Using the menu system select the Picture Adjuslmenr menu and select Reser Lo return lo factory saltings sae page 10 Distorted picture when changing programmes or selecting teletext Turn off any equipment connected lo lhe Scan connector on the rear of the TV Wrong characters appear when viewing teletext Using the menu system enter to the Language Country see page 12 menu and select the country7 in which you operate Lhe TV set For Cyrillic languages we recommend selecting Russia country if your own country does not appear in the list Pic lure si an led Using the menu system select the Picture Rotation op lion in Lhe De Lail Sei Up menu lo correct lhe picture slant see page 16 Noisy pic Lum when viewing a TV channel Using the menu system select the Manual Programme Iñ csct menu and adjust Fine 1 lining AF1 Lo obtain belter picture reception sou page 14 Using the menu system select the Noise Reduction op lion in the Detail Sei Up menu and select Auto lo reduce lhe noise in Lhe picture seo page 15 No unscrambled picture whilst viewing un unscrambled channel with a decoder connected through the Scart connector 0 2 4RI Using the menu system select the Set Up menu Then enter to Detail Set Up option and set AV2 Output lo IV see page 15 Remote control does not function Replace lhe ba Herios 1 he standby indicator on the 1V flashes Contact your nearest Sony service centre Standby Power Consumption Dimensions w x h x d Approx 788 x 598 к 523 mm Weight Approx 45 8 Kg Picture Tube Accessories supplied Dat Display IT Trinitron 29 approx 72 cm measured diagonally I Remo le C in trol R M 946 2 Batteries I FC design a led Rear Terminals leletcxt Faslext TOPtexl Sleep Timer SmartLink direct link between your TV set and a compatible VCR For more in forma lion on Smartl ink please refer lo the Instruction Manual of your VCR TV system Autodetection CÜ1I 5 Problem Other features 21 pin scan connector CRN RI FC standard including audio video input RGB input TV au d i o vi d ou tpu I 0 2 1 21 pin Scart connector SV1ARTI I N K CRN RI FC standard including audio video input S video input selectable audio video output and SmartLink interface Front Terminals D3 vi d co i npu L phono j ack 3 audio input phono jacks Q headphones jack Design and specifications are subject to change without notice Ecological Paper Totally Chlorine Free If you continue to experience problems have your TV serviced by qualified personnel Never open the casing yourself
