Controls & Connections (LCD)
Normal operation display
2 3 41
5
Default Display Mode FM Radio Broadcast Band
Dual Watch
1 VFO-A / VFO-B ................... 20 4 Battery Indicator ………… 19
2 S & PO Meter ..................... 22 5
FM Broadcast Band Frequency
………………………………
20
3 Operating Frequency ....... 21
The Set Mode and Preference Mode display
Set Mode Preferred Operating Mode
6
7
6 Set Mode Menu ................. 23 7
Preferred Operating Mode ............
.............................................
24
13FT-25R/FT-25E Operating Manual
