Sony ICD-BP100 [16/68] Select the folder

* The display selected with the DISPLAY button (page 39) appears.

Playing Back Messages

When playing back a previously recorded message, start from Step 1.

When playing back a message you have just finished recording, start from

Step 3.

Select the folder.

Select the message number .

Press . or > to

display the desired

message number.

>: for larger

message number

.: for smaller

message number

Selected

message

number

Current folder

Counter

display*

Press FOLDER

repeatedly to display

the folder (A, B or C)

you wish to play back.
