Philips 19HFL2829P/12 [32/39] Appendix 1

31

Appendix 1

Channel List Editor

Channel List Editor PC tool enables editing exported XML channel list files in a way that is more understandable and

user friendly.

3. Select the option “Export Channel list to USB”.

4. When the process is complete remove the USB key.

PC Tool can create a new empty channel without importing channels on TV, but we do not recommend this mode of

use due to the high level of possible errors that can be entered by user (wrong parameters or channel type).

When we export the channel list from TV, on USB drive there will be a file called “channelTable-00001.xml” in the

root folder. You can open that list for editing from within PC tool using Open option. It will import all the channels

and load them according to the Network Type (DVB-S, DVB-T...). Channel can be moved inside its Network Type,

added to favorites, channel info can be edited, removed, new channel can be added.

Note: Multiple versions of the channel plan can be saved on the USB flash drive. Correct naming is:

channelTable-00001.xml

For Channel List editor we recommend usage of a PC with Windows XP or Windows 7 and .Net framework 2.0 and

3.5 should be installed. Currently only English is supported for graphical user interface.
