Specifications
Specifications
CPU
y Supports 8th Gen Intel
®
Core
™
processors, and Intel
®
Pentium
®
and Celeron
®
processors for Socket LGA1151
Chipset Intel
®
Z370 Chipset
Memory
y 4x DDR4 memory slots, support up to 64GB
y Supports 4000+(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/
3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC)
/ 2800(OC)/ 2667/ 2400/ 2133 MHz*
y Dual channel memory architecture
y Supports non-ECC UDIMM memory
y Supports Intel
®
Extreme Memory Profile (XMP)
*Please refer to www.msi.com for more information on compatible memory.
Expansion Slots
y 3x PCIe 3.0 x16 slots
y 3x PCIe 3.0 x1 slots
Onboard Graphics
y 1x HDMI™ port, supports a maximum resolution of
4096x2160@30Hz, 4096x2160@24Hz, 2560x1600@60Hz
y 1x DVI-D port, supports a maximum resolution of
1920x1200@60Hz
Multi-GPU
y Supports 2-Way NVIDIA
®
SLI
™
Technology
y Supports 3-Way AMD
®
CrossFire
™
Technology
Storage
Intel
®
Z370 Chipset
y 6x SATA 6Gb/s ports*
y 2x M.2 slots (Key M)
Support up to PCIe 3.0 x4 and SATA 6Gb/s
Support PCIe 3.0 x4 NVMe U.2 SSD with Turbo U.2 Host
Card**
M2_1 slot supports 2242/ 2260 /2280/ 22110 storage
devices
M2_2 slot supports 2242/ 2260 /2280 storage devices
Intel
®
Optane™ Memory Ready***
* The SATA1, SATA5 and SATA6 ports will become unavailable with some
conditions of M.2 devices. Please refer to page 32 for M.2 & SATA combination
table.
** The Turbo U.2 Host Card is not included, please purchase separately.
*** Please refer to page 91 for Intel
®
Optane™ Memory Configuration.
Continued on next page
