MSI B350 GAMING PLUS [15/83] Specifications
![MSI B350 GAMING PLUS [15/83] Specifications](/views2/1307685/page15/bgf.png)
15
Specifications
Specifications
CPU
Supports AMD
®
RYZEN series processors and 7th Gen
A-series/ Athlon™ processors for Socket AM4
Chipset AMD
®
B350 Chipset
Memory
y
4x DDR4 memory slots, support up to 64GB
Support DDR4 1866/ 2133/ 2400/ 2667(OC)/ 2933(OC)/
3200(OC)+ Mhz*
y
Dual channel memory architecture
* 7th Gen A-series/ Athlon processors support a maximum of DDR4 2400 Mhz.
Please refer www.msi.com for more information on compatible memory.
Expansion Slots
y 1x PCIe 3.0 x16 slot (PCI_E2)
Supports x 16 speed with RYZEN Series Processors
Supports x 8 speed with 7th Gen A-series/ Athlon™
processors
y 1x PCIe 2.0 x16 slot (PCI_E4, supports x4 mode)*
y 2x PCIe 2.0 x1 slots
y 2x PCI slots
* PCI_E4 slot will support PCIe 2.0 x2 only, when installing device in any PCIe
x1 slot.
Multi-GPU y Supports 2-Way AMD
®
CrossFire™ Technology
Onboard Graphics
y 1x VGA port, supports a maximum resolution of
2048x1280@60HZ (RB)*
y 1x DVI-D port, supports a maximum resolution of
1920x1200@60Hz*
y 1x HDMI™ port, supports a maximum resolution of
4096x2160@24Hz*
* Only support when using a 7th Gen A-series/ Athlon™ processor
*Maximum shared memory of 2048 MB
Storage
AMD
®
B350 Chipset
y 4x SATA 6Gb/s ports*
Support RAID 0, RAID 1 and RAID 10
y 1x M.2 port (Key M)
Supports PCIe 3.0 x4 (RYZEN Series Processors) or PCIe
3.0 x2 (7th Gen A-series/ Athlon™ processors ) and SATA
6Gb/s
Supports 2242/ 2260 /2280/ 22110 storage devices
Audio
y Realtek
®
ALC892 Codec
y 7.1-Channel High Definition Audio
LAN y 1x Realtek
®
8111H Gigabit LAN controller
Continued on next page
