English
5
Z370 Extreme4
•
1 x Ultra M.2 Socket (M2_1), supports M Key type
2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2
PCI Express module up to Gen3 x4 (32 Gb/s)**
•
1 x Ultra M.2 Socket (M2_2), supports M Key type
2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module
and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)**
** Supports Intel® Optane
TM
Technolog y
** Supports NVMe SSD as boot disks
** Supports ASRock U.2 Kit
Connector
•
1 x COM Port Header
•
1 x TPM Header
•
1 x Power LED and Speaker Header
•
1 x RGB LED Header
* Supports in total up to 12V/3A, 36W LED Strip
•
1 x CPU Fan Connector (4-pin)
* e CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
•
1 x CPU Optional/Water Pump Fan Connector (4-pin)
* e CPU Optional/Water Pump Fan supports the water cooler
fan of maximum 1.5A (18W) fan power.
•
2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed
Control)
•
1 x Chassis Optional/Water Pump Fan Connector (4-pin)
* e Chassis Optional/Water Pump Fan supports the water
cooler fan of maximum 1.5A (18W) fan power.
* CHA_FAN1 and CHA_FAN2 can auto detect if 3-pin or 4-pin
fan is in use.
•
1 x 24 pin ATX Power Connector (Hi-Density Power
Connector)
•
1 x 8 pin 12V Power Connector (Hi-Density Power
Connector)
•
1 x Front Panel Audio Connector (15μ Gold Audio
Connector)
•
1 x underbolt AIC Connector (5-pin)
•
3 x USB 2.0 Headers (Support 6 USB 2.0 ports) (Intel® Z370)
(Supports ESD Protection)
•
1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports)
(Intel® Z370) (Supports ESD Protection)
