English

Z370 Extreme4

3.4 ASRock RGB LED

ASRock RGB LED is a lighting control utility specically designed for unique individuals with

sophisticated tastes to build their own stylish colorful lighting system. Simply by connecting the

LED strip, you can customize various lighting schemes and patterns, including Static, Breathing,

Strobe, Cycling, Music, Wave and more.

Connecting the LED Strip

Connect your RGB LED strips to the

RGB LED Header

(

RGB_LED)

on the motherboard.

1. Never install the RGB LED cable in the wrong orientation; otherwise, the cable may be

damaged.

2. Before installing or removing your RGB LED cable, please power o your system and

unplug the power cord from the power supply. Failure to do so may cause damages to

motherboard components.

1. Please note that the RGB LED strips do not come with the package.

2. e RGB LED header supports standard 5050 RGB LED strip (12V/G/R/B), with a

maximum power rating of 3A (12V) and length within 2 meters.

12V GRB

RGB_LED
