PCIe Slot Congurations (For CPU with 28 PCIe lanes)
PCIe Slot Congurations (For CPU with 16 PCIe lanes)
PCIE1 PCIE2 PCIE3 PCIE4 PCIE5 M2_1
Single Graphics Card x16 N/A N/A N/A N/A x4
Two Graphics Cards in
CrossFireX
TM
or SLI
TM
Mode
x16 N/A x8 N/A N/A x4
ree Graphics Cards in
3-Way CrossFireX
TM
Mode
or 3-Way SLI
TM
Mode
x8 N/A x8 N/A x8 x4
PCIE1 PCIE2 PCIE3 PCIE4 PCIE5 M2_1
Single Graphics Card x16 N/A N/A N/A N/A x0
Two Graphics Cards in
CrossFireX
TM
Mode
x8 N/A x4 N/A N/A x4
For a better thermal environment, please connect a chassis fan to the motherboard’s |
chassis fan connector (CHA_FAN1, CHA_FAN2 or CHA_FAN3) when using multiple
graphics cards.
* If you install CPU with 44 or 28 lanes and encounter CrossFire issues, please
do the followings.
1. Enter UEFI by pressing <F2> or <Del> during system startup.
2. Select “Boot > CSM” from the menu.
3.
S
et "Launch Storage OpROM policy" to "UEFI only".
4. Press F10 to Save and Exit.
