Asus WS C621E SAGE [11/122] Ws c621e sage series specifications summary

(continued on the next page)

WS C621E SAGE Series specifications summary

Model Name WS C621E SAGE WS C621E SAGE (BMC)

USB

ASMedia USB 3.1 Controllers

- 1 x USB 3.1 Type A port at back panel

- 1 x USB 3.1 Type-C™ port at back panel”

Intel

C621 Chipset

- 8 x USB 3.0 (4@ back panel, 4@ mid-board )

- 4 x USB 2.0 Ports (2@ back panel, 2@ mid-board)”

Audio

Realtek

ALC S1220A 8-Channel High Definition Audio CODEC

- Impedance sense for front and rear headphone outputs

- Supports : Jack-detection, Multi-streaming, front Panel MIC Jack-

retasking

- High quality 120 dB SNR stereo playback output and 113 dB SNR

recording input (Line-in)

- Front panel audio connector (AAFP)

- Supports up to 32-Bit/192kHz playback*

Audio Feature:

- DTS Connect

- DTS Headphone:X

- Premium Japanese-made audio capacitors: Provide warm, natural

and immersive sound with exceptional clarity and delity

- Unique de-pop circuit: Reduces start-up popping noise to audio

outputs

- Power pre-regulator: Reduces power input noise to ensure consistent

performance

* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for

8-Channel audio. 32-Bit/192kHz is only available under Windows

10.

Workstation Unique

Features

- 7 x PCIe x16 slots

- 10K hours Capacitors

- ProCool Power Connector

- Dr. Mos

- USB BIOS Flashback

- Beat Thermal Choke

- Digi+ VRM

- ASUS PIKE card (Optional)
