M.2 Anchor Installation

TheM.2Anchorisatool-lessdesigntoeasilyfasten

andsecureyourM.2SSDcardtoyourmotherboard

withoutusingextratools.

To install the M.2 SSD card using the M.2 Anchor:

1. LocatetheM.2mountingholeonyour

motherboardandrmlyinserttheM.2Anchor

intothehole.

2. InserttheM.2SSDcardintotheM.2slot.The

notchattheendoftheM.2SSDcardshallalign

withtherodoftheM.2Anchor.

3. FirmlyinsertthepinontheM.2Anchorintothe

holeonitself.

1. PulluptheringontheM.2Anchoruntilitis

separatedfromthehole.

2. RemovetheM.2SSDcardfromtheM.2slot.

To uninstall the M.2 SSD card:
