Asus PRIME J3355I-C [14/26] Rear panel connectors

1-6

Chapter 1: Product introduction

1. PS/2 mouse port (green).ThisportisforaPS/2mouse.

2. LAN (RJ-45) port.ThisportallowsGigabitconnectiontoaLocal

AreaNetwork(LAN)throughanetworkhub.

LAN port LED indications

Rear panel connectors

1 2

4 5

10 89 7

3. Video Graphics Adapter (VGA) port.This15-pinportisforaVGAmonitororother

VGA-compatibledevices.

4. Line In port (light blue).Thisportconnectstothetape,CD,DVDplayer,orother

audiosources.

5. Line Out port (lime).Thisportconnectstoaheadphoneoraspeaker.Inthe4.1,5.1

and7.1-channelcongurations,thefunctionofthisportbecomesFrontSpeakerOut.

6. Microphone port (pink).Thisportconnectstoamicrophone.

Refertotheaudiocongurationtableforthefunctionoftheaudioportsin2.1,4.1,5.1,or

7.1-channelconguration.

Activity/Link LED Speed LED

Status Description Status Description

Off Nolink OFF 10Mbpsconnection

Orange Linked ORANGE 100Mbpsconnection

Orange(Blinking) Dataactivity GREEN 1Gbpsconnection

Orange(Blinking

thensteady)

Readytowakeup

fromS5mode

_ _

LAN port

Speed

LED

Activity Link

LED
