Chapter 1: Product introduction

Chapter 1

4. EPU LED (O2LED1)

The EPU LED lights when the EPU switch is switched to Enable.

++E8044_M5A99X_EVO_R2.0_V2.indb 30 9/1/13 2:53:33 PM
