ASUS M5A99X EVO R2.0
2-3
Chapter 2
3. Place nine screws into the holes indicated by circles to secure the motherboard to the
chassis.
DO NOT overtighten the screws! Doing so can damage the motherboard.
++E8044_M5A99X_EVO_R2.0_V2.indb 3 9/1/13 2:53:41 PM
