Z270-WS specifications summary

(continued on the next page)

Storage

Intel

Z270 Chipset with RAID 0, 1, 5, 10 and Intel Rapid Storage

Technology 15 support*

- 1 x M.2_1 Socket 3 with M Key, type 2242/2260/2280/22110 storage

devices support ( PCIE mode only)**

- 1 x M.2_2 Socket 3 with M Key, type 2242/2260/2280/22110 storage

devices support (both SATA & PCIE mode)***

- 6 x SATA 6.0 Gb/s ports (gray)

- Supports Intel

Smart Response Technology****

- Supports PCIE RAID congurations via onboard U.2_1 and M.2_1 (and

U.2_2 or M.2_2) storages.

- 2 x U.2 connector (supports U.2 NVMe device) (U.2_2 connector***)

- Intel

Optane™ Memory Ready*****

* Supports PCIE RAID configurations via onboard U.2_1 and M.2_1 (and U.2_2 or

M.2_2) storages.

** The M.2_1 socket shares bandwidth with SATA6G_56 ports.

- When using M.2 PCIE devices in X2 mode, SATA_56 ports will not be disabled.

- When using M.2 PCIE devices in X4 mode, SATA_56 ports will be disabled.

*** The M.2_2 socket shares bandwidth with U.2_2 connector and SATA6G_1 port.

- When using M.2_2 socket with PCIE bandwidth, SATA6G_1 port will not be

disabled and U.2_2 connector will be disabled.

- When using M.2_2 socket with SATA bandwidth, SATA6G_1 port and U.2_2

connector will be disabled.

- When using U.2_2 connector, SATA6G_1 port will not be disabled and M.2_2

connector will be disabled.

**** These functions will work depending on the CPU installed.

***** Intel

Optane Technology is only supported when using 7th Generation Intel

processors. Before using Intel

Optane memory modules, ensure that you have

updated your motherboard drivers and BIOS to the latest version from ASUS

support website.

Audio

- Realtek

S1220A 8-ch HD, DTS

Connect/DTS

Headphone:X

- Crystal Sound 3

- Impedance sense for headphone outputs

- 120dB SNR stereo playback output & 113dB SNR input(Line-in) support

- Power pre-regulator reduces power input noise to ensure consistent

performance

- EMI protection cover to prevent electrical noise to affect the amplier

quality

- Unique de-pop circuit to reduce start-up popping noise to audio outputs

- Audio shielding ensures precise analog/digital separation and greatly

reduced multi-lateral interference

- Premium Japan-made audio capacitors provides warm, natural, and

immersive sound with exceptional clarity and delity

- Separate layer for left and right track, ensuring both sound deliver equal

quality

- Supports jack-detection, multi-streaming

- S/PDIF Optical Out
