Z270-WS specifications summary

CPU

Intel

Socket 1151 for 7th / 6th Generation Core™ i7/Core™ i5/Core™ i3/

Pentium

/Celeron

Processors

Supports 14nm CPU

Supports Intel

Turbo Boost Technology 2.0*

* The Intel

Turbo Boost Technology 2.0 support depends on the CPU types.

Chipset

Intel

Z270 Chipset

Memory

4 x DIMM, max. 64GB, DDR4 3866(O.C.) / 3733(O.C.) / 3600(O.C.) /

3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) /

3000(O.C.) / 2800(O.C.)* / 2666(O.C.)* / 2400/2133 MHz, non-ECC,

un-buffered memory

Dual channel memory architecture

Supports Intel

Extreme Memory Prole (XMP)*

* Hyper DIMM support is subject to the physical characteristics of individual CPUs.

Please refer to Memory QVL (Qualified Vendors List) for details.

Expansion slots

4 x PCI Express 3.0/2.0 x16 slots (single at x16; dual at x16/x16; triple at x16/x8/x8; quad

at x8/x8/x8/x8 mode)

1 x PCI Express 3.0/2.0 x4 slot* (max. at x4 mode, compatible with PCIe x1, x2 and x4

devices)

VGA

Integrated Graphics Processor- Intel

HD Graphics support

Multi-VGA output support: DisplayPort/HDMI port

Supports DisplayPort 1.2* with max. resolution 4096 x 2304@24Hz / 4096 x

2304@60Hz

Supports HDMI 2.0 with max. resolution 4096x2160@60/24Hz**

Supports High Dynamic Range (HDR), Wide Color Gamut (Rec.2020),

HDCP 2.2

Supports Intel

InTru™ 3D/Quick Sync Video/Clear Video HD Technology/

Insider™

Supports up to 2 displays simultaneously

Maximum shared memory of 1024MB

* DP 1.2 Multi-Stream Transport compliant, supports DP 1.2 monitor daisy chain

up to 3 displays

** HDMI 2.0 60Hz resolution support requires necessary drivers update

Multi-GPU

support

Supports NVIDIA

4-Way/Quad-GPU SLI

Technology * (with 4 PCIex16

graphics card)

Supports AMD

4-Way/Quad-GPU CrossFireX™ Technology(with 4 PCIex16

graphics card)

* Actual number of Multi-graphic supported differs per Vendors’ Graphic cards.

Please check with Vendor beforehand.

USB

Intel

Z270 Chipset

- 6 x USB 3.0/2.0 ports (4 ports @back panel, 2 ports @mid-board)

- 6 x USB 2.0/1.1 ports (4 ports @back panel, 2 ports @mid-board)

Asmedia

USB 3.1 controllers

- 2 x USB 3.1/3.0/2.0 ports @back panel (1 x Type A ; 1 x Type C)

- 1 x USB 3.1/3.0/2.0 port @mid-board (optional Type A or Type C)

(continued on the next page)
