Denyo DCA-800SPK [10/12] Options
![Denyo DCA-800SPK [10/12] Options](/views2/1308350/page10/bga.png)
Operation
Method
Engine
Starting/
Stopping
Synchronization
Verification/
Activation
Remarks
ManualParallel
OperationDevice
Standardfeaturefor
DCA-125to1100
Load
Sharing
AutomaticLoad
SharingDevice
ForDCA-150andabove
AutomaticParallel
OperationDevice
Autooperation
withpushbutton
ForDCA-220andabove.
Standardfeaturefor
DCA-1100SP
FullyAutomatic
ParallelOperation
Device
（
withEASYGEN
）
Semi-automatic
Automatic
Referto（4）belowfor
applicableunits.
Automatic
Manual
Manual
Manual
Manual
Manual
Automatic
Automatic
Automatic
Manual
Remote Control Devices
The engine generator can be remotely changed from low
speed to high speed operation, started and stopped, and
otherwise controlled. The ability to perform these
procedures automatically or manually at the location where
work is being performed when the engine generator is
separated by a considerable distance provides high fuel
and oil savings, extends engine life substantially, and leads
to a surprising level of reduction in manpower and energy
requirements. In addition, this also minimizes noise and
exhaust gas discharge levels, and in turn helps improve the
worksite environment.
Automatic Idling Device
Automatic Idling Device
（ Provided as standard feature for DCA-220 and above）
This device automates warm-up operation when the engine
is started. The addition of a remote-control box allows
remote changeover between low-speed and high-speed
operation.（Please note that the engine cannot be started
and stopped with the remote-control box.）
Remote Controller
（For DCA-220 to 1100）
This device allows the engine starting/stoppingand
automatic idling function（idling when engine is started） to be
operated from a remote location. In
addition to a switch for changeover
between high-speed and low-speed
operation, the remote-control box has
a high-speed/low-speed operation
indicator lamp, a startup warming
lamp
(
comes on when generator set is
not started up using normal remote controller operation
)
,and a
malfunction indicator lamp（illuminated when the emergency
stop device is triggered）.
Note: The remote-control box for the DCA-800SPM differs from the picture.
Automatic Oil Lubrication Device
（For DCA-25 to1100, provided as standard
feature for 610SPM, 800SPM, and 1100SPM2）
（Cannot be used with 25USI3,25ESK）
This system automatically maintains
engine oil at the proper level, making it
possible to reduce costs for oil-related
maintenance, and eliminates the need
to check the engine oil level.
Automatic Fuel Replenishment Device
（
For DCA-25ESI, 45 to 60）
When the level in the unit tank drops after an extended
period of operation, a level sensor detects this and an
electric pump is operated to automatically replenish fuel in
the unit tank from a separate tank.
（Cannot be used with three-way valve.）
Salt Corrosion Resistant Specifications
（For DCA-13 to DCA-220, provided as standard feature for DCA-300 and
above）
These specifications are designed for when the unit will be
used on the coast or on the ocean, and include treatment to
prevent insulation resistance from dropping, and corrosion
resistant treatment of the parts.
Parallel Operation Device
A variety of optional devices are available to change from manual
parallel operation to the desired type of automatic operation.
Select the desired option from the table below according to the
power supply application, site conditions and other factors.
（
1）Manual Parallel Operation Device: Parallel operation system with unique
Denyo AVR equipped with a cross-current compensation circuit（CCR
system）. This is the most inexpensive system, where no additional
equipment is required for the DCA-125 and above.
（2）Automatic Load Sharing Device: This device operates a governor motor to
share the load uniformly among the respective generators when parallel
operation is being performed. It facilitates stable parallel operation, and
dramatically reduces the workload of monitoring during parallel operation.
（3）Automatic Parallel Operation Device: The troublesome synchronization
verification and synchronization activation process can be automatically
performed by simply pressing a pushbutton. After synchronization is
activated, the Automatic Load Sharing Device is capable of performing
stable parallel operation.
（4）Fully Automatic Parallel Operation Device “EASY GEN”: High-speed
digital control enables all operations from starting and stopping to
synchronization verification, synchronization
activation and load sharing to be performed at
the touch of one button. This device has
multiple functions that enable parallel operation
of generators with differing capacities, the
number of units being operated to be controlled
and other operations.
Applicable models: DCA-220ESM, 600SPK,
610SPM, 800SPK, 1100SPK,1100SPM2
provided as standard feature for DCA-800SPM.
（5）The generator may be classified as a normal use generator according to the
Electricity Enterprises Law depending upon the installation and operation
procedure. Consult with a sales person for details.
Trailer
Trailers can be fitted to generators to facilitate on-site movement.
（
trailers for DCA-60 and below are two-wheel;those for DCA-75SP
through 400 are four-wheel
）
Bolt connectors make mounting and dismounting simple.
Options
9
Two-wheel type
Four-wheel type
EASY GEN 3500
