Preface
This manual is written for system integrators, IT professionals, and
knowledgeable PC users. It provides information for the installation and use of the
X10DRD-L/LT/i/iT/iNT motherboard.
About This Motherboard
The Super X10DRD-L/LT/i/iT/iNT motherboard supports dual Intel E5-2600v3/v4
Series processors (Socket R3) that offer new Intel Microarchitecture 22nm (E5-
2600v3)/14nm (E5-2600v4) Process technology, delivering system performance,
power efciency, and feature sets to address the needs of next-generation data cen-
ters. With the PCH C612 built in, the X10DRD-L/LT/i/iT/iNT motherboard supports
Intel® Node Manager 3.0, Intel MCTP Protocol, and Management Engine (ME).
This motherboard is ideal for general purpose, cloud computing server platforms,
optimized for the next-generation data centers. Please refer to our website (http://
www.supermicro.com) for CPU and memory support updates.
Manual Organization
Chapter 1 describes the features, specications, and performance of the moth-
erboard. It also provides detailed information about the Intel PCH C612 chipset.
Chapter 2 provides hardware installation instructions. Read this chapter when
installing the processor, memory modules, and other hardware components into
the system. If you encounter any problems, see Chapter 3, which describes
troubleshooting procedures for video, memory, and system setup stored in CMOS.
Chapter 4 includes an introduction to BIOS and provides detailed information on
running the CMOS setup utility.
Appendix A denes the BIOS error beep codes.
Appendix B lists software installation instructions.
Appendix C contains UEFI BIOS recovery instructions.
