Operation and Service megaSun 5600
1. General Safety Instructions
Please observe the following safety instructions:
Tanning times Please keep to the recommended tanning times.
See Section 9.1
Timer The apparatuses may only be operated with safety timers which
comply with the corresponding standards.
KBL-Solarien AG recommends the following timer:
megaTimer KBL-Article No. 9100025000.
Disconnecting Before opening the apparatus, switch off the fuses to disconnect
the system from the voltage supply!
Facial tanner
Shoulder tanner
Attention!
Do not operate the sunbed if a filter pane is defective.
Section 5.3
Do not operate the shoulder tanner without lamp unit
Attention! High light intensity, do not look into the radiators!
Technical
Parameters
Mains voltage
The data indicated in the tanning schemes are based on the
assumption that both tubes and burners are replaced at regular
intervals. Section 5.4
When replacing tubes, remember to reset the CPI-control
system (Section: 8.2) and the counter of the tube service hours
(Section: 8.3).
An FI protective switch is required in any case.
Mechanics The canopy drive has to be serviced regularly with each tube
replacement.
This also includes the replacement of the drive rope after 3,000
hours of operation.
Section 5.8
Please also keep to the service cycles given in the service plan
(Section 2).
Cleaning Do not use any cleaning agents other than the ones approved
by KBL Solarien AG. Section 5.1
