u
To
switch
on:
using the Up setting button, upper
wine zone
Fig. 3 (8)
or Down setting button, upper
wine zone
Fig. 3 (7)
select c1.
u
To switch off: using the Up setting button, upper
wine zone
Fig. 3 (8)
or Down setting button, upper
wine zone
Fig. 3 (7)
select c0.
u
To confirm: press the fan button
Fig. 3 (10)
.
w
The
child-proofing
function
is switched on when the child-
proofing symbol
Fig. 3 (6)
shines.
u
To deactivate the setting mode: press the On/Off button
Fig. 3 (9)
.
-or-
u
Wait for 5 minutes.
w
The temperature is indicated again in the temperature
display.
5.3 Door alarm
5.3.1 Muting the door alarm
The audible alarm can be muted when the door is open. The
sound switch-off function is active as long as the door is left
open.
u
Press alarm button
Fig. 3 (4)
.
w
The door alarm is silenced.
5.4 Temperature alarm
The audible alarm sounds if the wine storage
temperature is too warm or too cold.
The temperature display flashes at the same time.
The cause of the temperature being too high may be:
-
warm fresh food was placed inside
-
too
much warm
ambient air flowed in when rearranging and
removing food
-
power failure for some time
-
the appliance is faulty
The audible alarm is automatically silenced and the tempera-
ture display stops flashing when the temperature is sufficiently
cold/warm again.
If the alarm status persists: (see Malfunction).
Note
Food may be spoilt if the temperature is not cold enough.
u
Check the quality of the food. Do not consume spoiled food.
5.5 Storing wine bottles
64 Bordeaux bottles (0,75 l) can be stored in the wine zone.
u
Store
white
wine
only in one compartment and red wine only
in the other, since both compartments can be set to inde-
pendent temperatures.
u
If possible, lay bottles of the same type of wine side by side
on the same grid shelf.
u
Rearrange bottles as seldom as possible.
u
Stored open bottles
on the
folded down wooden grid
shelf.
u
To fold down the wooden
grid shelf: press the lock
under the trim sideways.
w
The wooden grid shelf folds
down.
5.6 Setting the temperature in the wine
zone
The appliance is
pre-set for normal operation. The temperature
can be set from 20 °C to 5 °C, the recommended temperatures
are 8 °C to 12 °C.
The wine zone is divided into two wine compartments, which
can be set to different temperatures, as needed.
u
To set the temperature warmer: press the Up setting button,
upper wine zone
Fig. 3 (8)
or Up setting button, lower wine
zone
Fig. 3 (2)
.
u
To set the temperature colder: press the Down setting
button, upper wine zone
Fig. 3 (7)
or Down setting button,
lower wine zone
Fig. 3 (3)
.
u
To change the temperature in 1 °C steps: briefly press the
button.
-or-
u
To change the temperature continuously: hold down the
button.
w
During setting the new value is displayed flashing.
w
The actual temperature is displayed about 5 s after the last
press of a button. The temperature slowly adjusts to the new
value.
5.7 Fan
When the fan runs, the relative humidity in the interior
increases so that the cork does not dry out.
When the fan is activated, the energy consumption increases.
To save energy, the fan switches off automatically when the
door is open.
5.7.1 Switching on the fan
u
Briefly press the
fan button
Fig. 3 (10)
.
w
The fan button
Fig. 3 (10)
shines.
w
The fan always runs. The humidity is high.
5.7.2 Switch off the fan
u
Briefly press the fan button
Fig. 3 (10)
.
w
The fan button
Fig. 3 (10)
does not shine.
w
The fan runs only when this is necessary for temperature
control. The humidity is low.
5.8 Labels
You can note down on the labels the type of wine stored in the
respective compartment. Additional labels can be obtained
from your specialist dealer.
5.8.1 Labelling
5.9 Wooden shelf
Pay attention that the wooden
shelf does not
get caught on the
rear hook.
u
To remove the folding
wooden shelf: lift it off the
pull-out rail and draw it
forwards.
Control
22
