Instructions for the Installer

In case of connection to the electrical mains by means of socket and pin,

the connection must be completed with a three-pin plug of suitable rating

(25A), or, for operation at 380-415V2N∼ or 380-415V3N∼, a five-pin plug

(16A). The power supply plug and wall socket must be of the same type

(in compliance with CEI standards). Check that the power supply line is

properly earthed. The use of reductions, adapters or junctions is not

recommended.

If a permanent connection to the elctrical mains is used, the appliance's

power supply line must be fitted with an omnipolar breaking device with

contact breaking gap of at least 3 mm, located in an easily accessible

position close to the appliance itself.

WARNING: if the mains voltage drops below 190 VAC there might be

an impairment of the oven's performance; this is not due to the

appliance itself.

2.1.1 Safety thermostat

The oven is fitted with a safety device tripped in case of a serious

malfunction. To reset the safety device, call the after-sales service.

The manufacturer declines all responsibility for injury or damage

caused by failure to comply with the above regulations or deriving from

tampering with even just one part of the appliance.

2.2 Levelling

Level the oven by means of its four adjustable feet. To make the

adjustment, undo the lock-nut and unscrew the foot. The adjuster screw

travel is 10 mm.

2.3 Steam vent pipes

Depending on the model, the back of

the oven is fitted with two pipes

which vent the steam produced

during cooking. These pipes must

be left free of all obstructions. Take

care not to crush them.
