ENGLISH
23
OPERATION
WHEN SHOULD THE HOOD BE SWITCHED ON AND OFF?
Switch on the hood at least one minute before starting to cook: this enhances the airow to convey fumes and vapours towards the suction surface.
After cooking, leave the hood operating until complete extraction of all vapours and odours. If required, by means of the Timer function, it is possible
to set hood auto switch-o after 15 minutes of operation.
WHICH SPEED IS TO BE SELECTED?
The rst speed is a low consumption energy-saving way of keeping the air clean, the second speed is used in normal conditions, and the third
speed is used when there are strong odours and vapours.
WHEN SHOULD THE FILTERS BE WASHED OR REPLACED?
The hood is assembled with two dierent types of lters: metal ones (washable) and active carbon ones (non-washable). The former must be
cleaned every 30 hours of use (the xed light
indicates that they need to be washed), the latter are to be replaced every 3-4 months, depending
on the use of the hood. For further information, please read the chapter regarding "Maintenance" on page 25.
WHEN AND WHY TO USE THE RECIRCULATION FUNCTION
The recirculation function can be used to improve the quality of the air in the home.
When the function is switched on, the hood recirculates the air in the room through an operating cycle at the 1st speed for 1 hour, followed by 3
hours, during which time the motor is down. This cycle is repeated for 24 hours, until timeout.
This function is useful with hoods installed with the external exhaust (suction) version.
TOUCH BUTTON PANEL OPERATION
24h
Touch keyboard operation
The hood's touch keyboard is used by pressing the screen printed keys with dry, clean ngers: use ngers only and not other objects such as
ladles, cutlery, etc.
The use of a touch keyboard makes it much easier to clean the glass panel and also guarantees maximum, long-lasting reliability, avoiding any
type of mechanical problem.
Key pressure management :
Long press: nger pressed on key for at least 3 seconds, the function comes on while it is pressed.
Short press: nger pressed on key for less than 3 seconds, the function comes on when the key is released.
Timer/Filters alarm
Pressing the key with the motor active at any speed switches the Timer function on and o: this function determines the auto switch-
o of the hood after 15 minutes of operation. When the function is on the relative LED will start ashing, red or blue depending on
the model.
With the Timer function active, the hood can still be switched o by the user at any time by pressing the "speed 1" key: the function will
be automatically disabled and the relative light will turn o. With some models this also happens when the speed is changed while the
Timer function is running.
On the other hand, lights up steady indicating the grease lter alarm: this alarm reports that it is time to wash the metal anti-grease
lters (the alarm is triggered after approximately 30 hours of use). After cleaning the lters, disable the alarm and reset the counters by
keeping the key pressed for 3 seconds.
To disassemble and assemble the anti-grease metal lters, refer to the instructions P on page 9.
24h
Speed 1 button
With LED on (speed 1 already running):
r Pressing this key will switch o the hood motor and the LED associated with the key
With LED o:
r A short press starts or sets the hood at speed 1 (the function starts when the key is released); when speed 1 is running, the relative
LED lights up.
r With the motor o, a long press (at least 3 seconds) will start the recirculation function: in this mode (for 24 hours), the hood runs an
operating cycle which involves starting the motor at the 1st speed for 1 hour, followed by 3 hours with the motor down. This cycle is
repeated for 24 hours, until timeout. For these 24 hours, the LED ashes, meaning that the recirculation function is running. With this
feature enabled, you CANNOT select other speeds.
r To deactivate this function, keep the relative key pressed for at least 3 seconds.
