CRYSTAL VENUS 46 VITRINE (CURVED) гнутое стекло [2/7] Introduction

1. INTRODUCTION

Proper installation and maintenance are essential for maximum satisfaction from your appliance. It is

therefore necessary to carefully read and observe the indications of these instructions for use.

2. TRANSPORT (Figure 1)

3. INSTALLATION

─ Unpack the appliance.

─ Make sure the appliance is stable and in horizontal position.

─ The appliance is equipped with wheels. Make sure the floor surface is not inclined and it facilitates the

appliance’s transport and installation.

─ Never install the freezer in a room exposed to direct sun radiation nor in the vicinity of a heat source such as

cooker, a stove, a heater, a fireplace, etc.

─ Avoid installing the appliance in confined rooms, damp, and without airing or in wall recesses.

─ Make sure that the distance between the wall or other large objects and the back and left side of the appliance is

at least 10 cm. This distance is the minimum required to ensure normal ventilation of the refrigeration

mechanism.

4. ELECTRICAL CONNECTION

Make sure that the feed cable and the socket is appropriate for the appliance power. In case of doubt, contact

a qualified technician.

Before inserting the plug in the mains outlet, make sure the voltage mentioned on the nameplate on the back

side of the appliance, complies with the one of your network. A discrepancy of ± 10% is acceptable.

Too high or too low voltage network may seriously damage the compressor. Such damages are not covered

by the guarantee. The appliance must be earthed as prescribed by the relevant legislation whereas it is indispensable

for your personal safety. The manufacturer has provided for earthing in the electrical installation and external

surface of the appliance.

NOTE: Upon start-up, running may be noisy. Noise will only last for the engine “running in” time and

will dim progressively.

5. OPERATION

Once the appliance installed, wait for at least fifteen minutes before start-up. Afterwards, insert the plug in

the mains outlet.

Make sure that the thermostat – located on the left side of the appliance – is set on the proper position (not 0)

and the indication lamp (located at the front side) is on (except for model VETRINE 16).

Start-up the freezer with no loads and make sure that the glasses (sliding lids) are properly closed. Wait at

least 1,5 hour before reaching the appropriate temperature inside the appliance.

If you wish to accelerate the freezer’s preparation set the thermostat on position 7. Store the products and

reset the thermostat in the middle of the scale.

WARNING: do not store products exceeding the load line limit (indicative red horizontal line in the

interior of the freezer).

Products are good to be packaged.

WARNING: do not store warm products in the freezer (temperature higher than ambient temperature

20º to 25º C). This could lead to malfunctioning of your appliance and spoiling of the products.

Always transport the appliance in horizontal position; do

not overturn it and do not load it in leaning position.

Figure 1
