Precautions and trips

ATTENTION

! Before placing your new appliance into operation please

read these operating instructions carefully. They contain

important information for safe use, for installation and for

care of the appliance.

! Please keep these operating instructions for future

reference. Pass them on to possible new owners of the

appliance.

1. This appliance is designed to be used indoors and

under no circumstances should it be installed outside

even if protected by a roof. Leaving the appliance ex-

posed to the rain and whether is exceedingly dangerous.

2. The appliance should be used only by adults and exclus-

ively for storing foodstuffs in compliance with the instructions

provided in this manual. Under no circumstances should

children be allowed to operate, or tamper with, this product.

3. The appliance is not intended for use by people

(including children) with low physical, sensory or mental

abilities or if they don’t have life experience or

knowledge unless they are kept under control or have

been instructed by the person responsible for their

safety how to use the appliance. Children should be

controlled to avoid playing with the appliance.

4. It is highly recommended that you do not operate this ap-

pliance by connecting it to the power supply with extensions

or multiple socket plugs. If the refrigerator has been installed

between two cabinets, make sure that the supply cord is not

dangerously crimped or trapped beneath a heavy object.

5. Never pull the cable or the appliance to remove the plug

from the socket; this is exceedingly dangerous.

6. Do not touch the internal cooling elements, especially if

your hands are wet, since you could burn or hurt yourself.

7. Before doing any cleaning, disconnect the appliance

from the electricity (by pulling out the plug or turning off

the general switch in your home).

8. Before disposing of your old appliance, remember to

break or remove the lock as a safety measure to protect

children who might lock themselves inside the appliance

when playing. In addition, if the appliance is a new one

with a lock, keep the key out of the reach of small children.

9. If your appliance is not operating properly, read the

chapter entitled, “Trouble Shooting”, which might help

you to resolve the problem, before calling an after-sales

service center. Do not attempt to repair the appliance by

tampering with the internal components.

10. If the power supply cord must be replaced, please

contact one of our Customer Service Centers. In some

cases, the connections are made using special terminals

and in others a special tool must be used to access the

connections.

11. Do not use electric appliances inside the compartment

for food storage, if these are not those recommended by the

manufacturer.

12. At the end of the functional life of your appliance

containing cyclopentane gas in the insulation foam the

latter should made safe before being sent to the dump.

For this operation, please contact your dealer or the Local

Organization in charge of waste disposal.

The European Directive 2002/96/EC on Waste Electrical

and Electronic Equipment (WEEE), requires that old

household electrical appliances must not be disposed

of in the normal unsorted municipal waste stream. Old

appliances must be collected separately in order to

optimize the recovery and recycling of the materials they

contain and reduce the impact on human health and the

environment. The crossed out “wheeled bin” symbol on

the product reminds you of your obligation, that when you

dispose of the appliance it must be separately collected.

Consumers should contact their local authority or retailer

for information concerning the correct disposal of their old

appliance.

CAUTION

There is small quantity of refrigerant (R600a) in the

refrigerator, it is isobutane natural gas which doesn’t cause

damage to environment, but is ﬂ a m m a b l e . I t ’ s n e c e s s a r y

to transport and install the refrigerator with care so that not

to damage any refrigerant circuit parts.

Nevertheless if the refrigerant circuit has been damaged

please avoid any types of open ﬂ a m e o r p o t e n t i a l

inﬂ a m m a t i o n s o u r c e s a n d a i r t h e r o o m c a r e f u l l y .

To avoid formation of ﬂ a m m a b l e m i x o f g a s a n d a i r i n

case of refrigerant leakage, the size of the room where

the refrigerator is should correspond to the quantity of

the refrigerant used in the refrigerator. The room volume

should be 1mі for each 8g of R600a refrigerant in the

appliance. The quantity of the refrigerant contained in

your particular refrigerator is speciﬁ e d o n t h e r a t i n g s l a b e l

inside the refrigerator.

Never plug in the refrigerator having signs of damage. If

you have any doubts of the appliance operable condition,

please apply to the authorized service center.

CAUTION! Don’t use any electric devices inside the

refrigerator.

CAUTION! Don’t block up vent holes that are located

in the appliance body or in the build-in construction.

CAUTION! Avoid damaging of the refrigerant circuit.

CAUTION! Don’t use mechanical devices or other

means to speed up defrosting process except those

that are recommended by the manufacturer.

Description of the appliance

ON/OFF - it is possible to switch the whole product (both the

refrigerator and freezer compartments) on by pressing this

button. The red LED indicates that the product is switched off,

while the green LED shows that it is operating.

OFF state: to turn the fridge off is sufficient to press once the

ON-OFF button

his is used to activate and deactivate the I Care

function (the optimal temperature for energy saving levels).

When activated, the AUTO LED and the I Care LED illuminate

simultaneously.

ALARMS - this controls all the alarm signals connected to

product operation.

Child Lock - enables the buttons on the control panel to be

locked in order to avoid various functions being activated

accidentally by children. To enable the Child Lock function,

button must be pressed for 2 seconds.

REFRIGERATOR Temperature Adjustment - enable the

temperature setting of the refrigerator to be modified, with the

relative confirmation of the temperature selected shown on the

display. It is also possible to use these buttons to deactivate

the refrigerator compartment only.

FREEZER Temperature Adjustment

- enable the temperature setting of the freezer

to be modified, with the relative confirmation

of the temperature selected shown on the display.

SUPER COOL - activates or deactivates the SUPER COOL

function (rapid cooling).

SUPER FREEZE - activates or deactivates the SUPER

FREEZE function (rapid freezing).

HOLIDAY - activates or deactivates the HOLIDAY function

(the I Care il l u m in at e s ) .

ICE PARTY - activates or deactivates the ICE PARTY function

(It reduces the temperature of the freezer for the period of time

required to cool a bottle.).

Display Standby: the display turns all its LEDs off if I Care or

Holiday Fcn are active and the last interaction with the user is

more than 10 minutes far.

Navigating the display

If the product is switched on, the refrigerator and freezer

displays will indicate the temperatures set at that moment. To

change them, simply press the buttons corresponding to the

compartment for which you wish to change the set

temperature. To be specific, each time one of the buttons is

pressed the temperature is increased or decreased by 1°, and

the number of illuminated horizontal bars is adjusted

accordingly. The temperature values that may be selected for

the refrigerator compartment are +8°C, +7°C, +6°C,

+5°C,+4°C, +3°C and +2°C, while the values that may be set

for the freezer are -18°C, -19°C, -120°C, -21°C, -22°C, -24°C

and -26°C. I

When the I CARE function is active, the appliance

automatically adjusts the temperatures according to the

conditions inside and outside the refrigerator; the operation of

this function is signaled by the text “I Care”. Whenever it is

necessary to activate the I CARE function at temperatures

that are different to the standard storage values, the I CARE

button must be pressed as soon as the function is activated

and held down while the new temperatures are set. Under

these conditions, the temperatures may

be set to 4°C, 5°Cand

6°C for the refrigerator compartment and -18°C, -19°C and -

20°C for the freezer compartment.

When the HOLIDAY f un c ti o n is a ct i ve t h e t e mp e ra t u re m ay no t

be adjusted, however the appliance adjusts itself

automatically so that the optimal settings for the situation are

used: +12°C for the refrigerator compartment and -18°C. for

the freezer compartment. This function is indicated by the text

“I Care”.

To a ct iv a t e a n d de a c t iv at e t he fu n c t i o ns s i mp l y press the

relevant button and the function status will be signaled by the

corresponding LED switching on or off.

Several functions (SUPER COOL, SUPER FREEZE, ICE

PARTY, I Care) are incompatible with others( HOLIDAY);

remember that there is a pre-set order of priority wh i ch will he l p

you to use the product in the best possible way.

When the ICE Party function has finished, press the ICE Party

button to stop the relevant LED from flashing. This flashing

indicates that the function is complete and that the bottle

should be removed from the freezer compartment.

Child Lock to enable the Child Lock function, the button must

be pressed for 2 seconds.

Temperature

Control

Electronic

OPTIONS

I care

ON/OFF

Select button

refrigerator

Select button

freezer

ICE PARTY

Indicat refriger

Indicat freezer

HOLIDAY

SUPER FREEZ

I Care

SUPER COOL
