Содержание
- Air conditioner 2
- Installation manual 2
- Caution 3
- Safety information 3
- Warning 3
- Caution 4
- English 4
- External dimensions 5
- Optional accessories 5
- Unit mm inch 5
- Wired remote controller installation 5
- English 6
- Wired remote controller installation 6
- Align the controller with the upper groove first and insert it by turning it downward as shown in the figure after assembly check and confirm that no wires are stuck in the gap between the rear and front cover 7
- Mm 0 inch or more 7
- Mm 2inch or more 7
- Reassemble your wired remote controller 7
- Using more than two screws firmly affix the rear cover of the remote controller to the wall and then connect the communication power cable f3 f4 or 3 4 making sure these cables have reasonable length to the terminal at the back of the cover 7
- When installing your wired remote controller on the wall consider the size of the wire hole and select a wire with a proper thickness wire that is connectable to wired remote controller pcb if you install the wired remote controller by reclaiming install it according to u terminal cable specification if you install the wired remote controller by using two pieces of pvc wire remove the 30cm 12inch of the sheath of the cable and install it only with the two pieces of wires recommended specification awg21 the following are the specs of the compression ring terminal connected to your wired remote controller pcb 7
- Wired remote controller installation 7
- English 8
- Tracking your indoor unit from the wired remote controller 8
- Individual control with your wired remote controller 9
- When connected to an indoor unit only 9
- When connected to an ventilator erv only 9
- Wired remote controller installation 9
- 1 using one wired remote controller to control three indoor units 10
- 2 using one wired remote controller to control indoor units connected to different outdoor unit 10
- English 10
- Group control with your wired remote controller 10
- When connected to an indoor unit only 10
- 1 using one wired remote controller to control three ventilator erv 11
- When connected to an ventilator erv only 11
- Wired remote controller installation 11
- 1 using one wired remote controller to control multiple indoor units and ventilator erv 12
- English 12
- Using one wired remote controller to control indoor units connected to different outdoor unit and ventilator erv 12
- When connected to an indoor unit and an ventilator erv together 12
- Controlling 2 remote controller 13
- For the slave wired remote controller settings please refer to the sections about the additional functions of the wired remote controller refer to page20 0 master 1 slave 13
- Master ventilator erv 13
- Outdoor unit 13
- Remote controller is controlling one indoor unit ventilator erv or one group of indoor units and ventilator erv with two remote controllers 13
- Ventilator erv 13
- When connected to an indoor unit only 13
- When connected to an ventilator erv only 13
- Wired remote controller installation 13
- English 14
- Outdoor unit 14
- Regardless of the indoor unit group address rmc address only the indoor units connected to com2 are controlled by 2 remote controller for the slave wired remote controller settings please refer to the sections about the additional functions of the wired remote controller refer to page20 0 master 1 slave 14
- When connected to an indoor unit and an ventilator erv together 14
- Initializing your wired remote controller communication 15
- Wired remote controller installation 15
- English 16
- Errors displayed on your wired remote controller 16
- Wired remote controller error codes 17
- Wired remote controller installation 17
- Additional functions of your wired remote controller 18
- Wired remote controller installation service mode 18
- Wired remote controller installation service mode 19
- Additional functions of your wired remote controller 20
- English 20
- None will be displayed if the indoor unit does not support the function in some cases the setting may not possible or it may be not applied though it is set on the unit if communication initialization is needed after the setting the system will reset automatically and communication will be initialized 20
- Description unit 21
- Main menu sub menu function data bit 21
- Wired remote controller installation service mode 21
- Button to go to the next page 22
- English 22
- If you enter main menu 4 you must select the targeted indoor unit address and then select the sub menu 22
- Power master reset is a setting needed to supply optimized power to wired remote controller when multiple indoor units are connected to wired remote controller in a group 22
- Seg1 seg2 seg3 seg4 seg5 seg6 0 22
- Seg13 seg14 seg15 seg16 seg17 seg18 2 22
- Seg19 seg20 seg21 seg22 seg23 seg24 3 22
- Seg7 seg8 seg9 seg10 seg11 seg12 1 22
- Setting is available when there is only 1 indoor unit connection and while the indoor unit operation is not operating 22
- The example of wired remote controller option setting method 23
- Wired remote controller installation service mode 23
- English 24
