10
Wired Remote Controller Installation
When Connected to an ventilator(ERV) Only
(1) Using One Wired Remote Controller to Control Three ventilator(ERV)
Wired Remote
Controller
COM2(F3, F4)
Master ventilator(ERV)
COM1(F1, F2)
Ventilator(ERV) Ventilator(ERV) Ventilator(ERV)
COM1(F1, F2)
COM2(F3, F4)
COM1(F1, F2)
• Regardless of the ventilator(ERV)'s group address (RMC address), only the ventilator(ERV) connected to COM2
controlled in group.
uhzh~GyGjt~yT~lXWuluptWZ^X]hOXPUGGGXW YWXZTWYTWXGGG㝘䟸G]aZ[aW_
