12
7. Specifi cations
Having trouble? Here is the solution. (Unit is operating normally.)
Noise is louder than specifi cations.
■
The indoor operation sound level is affected by the acoustics of the
particular room as shown in the following table and will be higher than
the noise specifi cation, which was measured in anechoic room.
High sound
absorbing rooms
Normal rooms
Low sound
absorbing rooms
Location
examples
Broadcasting
studio, music
room, etc.
Reception room,
hotel lobby, etc.
Offi ce, hotel
room
Noise levels 3 to 7 dB 6 to 10 dB 9 to 13 dB
Nothing appears in the wireless remote controller display, the display
is faint, or signals are not received by the indoor unit unless the remote
controller is close.
■
The batteries are low.
Replace the batteries and press the Reset button.
■
If nothing appears even after the batteries are replaced, make sure that
the batteries are installed in the correct directions (+, –).
The operation lamp near the receiver for the wireless remote controller on
the indoor unit is blinking.
■
The self diagnosis function has operated to protect the air conditioner.
■
Do not attempt to repair this equipment by yourself.
Turn off the power switch immediately and consult your dealer. Be sure
to provide the dealer with the model name.
6. Trouble Shooting
Model
PLA-RP35BA PLA-RP50BA PLA-RP60BA PLA-RP71BA PLA-RP100BA PLA-RP125BA
PLA-RP140BA2
Power source (voltage <V>/Frequency <Hz>)
~/N 230/50
Rated Input (Indoor only)
<kW>
0.03 0.05 0.05 0.07 0.14 0.15 0.16
Rated Current (Indoor only)
<A>
0.22 0.36 0.36 0.51 0.94 1.00 1.07
Heater <kW>
-------
Dimension (Height)
<mm>
258 (35) 298 (35)
Dimension (Width)
<mm>
840 (950)
Dimension (Depth)
<mm>
840 (950)
Fan airfl ow rate (Low-Middle2-Middle1-High)
<m
3
/min>
11-12-13-15 12-14-16-18 12-14-16-18 14-16-18-21 20-23-26-30 22-25-28-31 24-26-29-32
Noise level (Low -Middle2-Middle1-High)
<dB>
27-28-29-31 28-29-31-32 28-29-31-32 28-30-32-34 32-34-37-40 34-36-39-41 36-39-42-44
Net weight
<kg>
22 (6) 23 (6) 25 (6) 27 (6)
Model
PLA-RP71BA2
PLA-RP100BA3 PLA-RP125BA2
Power source (voltage <V>/Frequency <Hz>)
~/N 230/50
Rated Input (Indoor only)
<kW>
0.07 0.15 0.16
Rated Current (Indoor only)
<A>
0.51 1.00 1.07
Heater
<kW>
---
Dimension (Height)
<mm>
258 (35) 298 (35)
Dimension (Width)
<mm>
840 (950)
Dimension (Depth)
<mm>
840 (950)
Fan airfl ow rate (Low-Middle2-Middle1-High)
<m
3
/min>
14-16-18-21 20-23-26-30 22-25-28-31
Noise level (Low -Middle2-Middle1-High)
<dB>
28-30-32-34 32-34-37-40 34-36-39-41
Net weight
<kg>
23 (6) 26 (6) 27 (6)
Model
PLA-ZRP35BA PLA-ZRP50BA PLA-ZRP60BA PLA-ZRP71BA PLA-ZRP100BA PLA-ZRP125BA PLA-ZRP140BA
Power source (voltage <V>/Frequency <Hz>)
~/N 230/50
Rated Input (Indoor only)
<kW>
0.04 0.04 0.04 0.05 0.08 0.09 0.12
Rated Current (Indoor only)
<A>
0.28 0.30 0.30 0.45 0.74 0.80 1.07
Heater
<kW>
-------
Dimension (Height)
<mm>
258 (35) 298 (35)
Dimension (Width)
<mm>
840 (950)
Dimension (Depth)
<mm>
840 (950)
Fan airfl ow rate (Low-Middle2-Middle1-High)
<m
3
/min>
11-13-15-16 12-14-16-18 12-14-16-18 17-19-21-23 20-23-26-30 22-25-28-31 24-26-29-32
Noise level (Low -Middle2-Middle1-High)
<dB>
27-28-29-31 28-29-31-32 28-29-31-32 28-30-34-36 32-34-37-40 34-36-39-41 36-39-42-44
Net weight
<kg>
23 (6) 25 (6) 26 (6) 27 (6)
*1 The fi gure in ( ) indicates Grille’s.
